TeSys K Differential Thermal Overload Relay (1.2-1.8A, Class 10A)
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$101.83 each
In Stock
MANUALS (1)
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
1.8 Amps
18 Month Warranty
Description
–
TeSys K Differential Thermal Overload Relay (1.2-1.8A, Class 10A)
Specifications:
Specifications:
- Range: TeSys
- Product or Component Type: Differential Thermal Overload Relay
- Relay Application: Motor Protection
- Product Compatibility: LC1K, LP1K, LP4K, LC7K
- Network Type: AC, DC
- Thermal Overload Class: Class 10A IEC 60947-4-1
- Thermal Protection Adjustment Range: 1.2…1.8 A
- [Ui] Rated Insulation Voltage: Power Circuit 690 V BS 4941, Power Circuit 690 V IEC 60947, Power Circuit 750 V VDE 0110 group C, Power Circuit 600 V CSA C22.2 No 14
- Network Frequency: <= 400 Hz
- Mounting Support: Plate, with Specific Accessories, Rail, with Specific Accessories under Contactor
- Auxiliary Contact Composition: 1 NO + 1 NC
- [Ith] Conventional Free Air Thermal Current: 6 A Signalling Circuit
- [Ue] Rated Operational Voltage: <= 690 V Power Circuit, 690 V AC AC-15 Signalling Circuit, 250 V DC DC-13 Signalling Circuit
- Associated Fuse Rating: 6 A gG Signalling Circuit VDE 0660, 6 A gG Signalling Circuit IEC 60947
- [Uimp] Rated Impulse Withstand Voltage: 6 kV
- Power Dissipation per Pole: 2 W
- Phase Failure Sensitivity: Yes IEC 60947-4-1
- Local Signalling: Trip Indicator Yellow
- Control Type: Red Push-Button Trip Test Function, Blue Push-Button Stop and Manual Reset, Selector Switch Manual or Automatic Reset
- Connections - Terminals: Screw Clamp Terminals 1 0.00…0.01 in² (1.5…4 mm²) Solid, Screw Clamp Terminals 2 0.00…0.01 in² (1.5…4 mm²) Solid, Screw Clamp Terminals 1 0.00…0.01 in² (0.75…4 mm²) Flexible without Cable End, Screw Clamp Terminals 2 0.00…0.01 in² (0.75…4 mm²) Flexible without Cable End, Screw Clamp Terminals 1 0.00…0.00 in² (0.34…2.5 mm²) Flexible with Cable End, Screw Clamp Terminals 2 0.00…0.00 in² (0.34…1.5 mm²) Flexible with Cable End
- Tightening Torque: 11.51 lbf.in (1.3 N.m) Screw Clamp Terminals Philips No 2, 11.51 lbf.in (1.3 N.m) Screw Clamp Terminals Flat Ø 6 mm
- Standards: IEC 60947, NF C 63-650, VDE 0660, BS 4941
- Product Certifications: UL, CSA
- Protective Treatment: TC IEC 60068, TC DIN 50016
- IP Degree of Protection: IP2x IEC 60529
- Ambient Air Temperature for Operation: -4…131 °F (-20…55 °C) without Derating IEC 60947, -22…140 °F (-30…60 °C) with Derating IEC 60947
- Ambient Air Temperature for Storage: -40…158 °F (-40…70 °C)
- Operating Altitude: 6561.68 ft (2000 m) without Derating
- Fire Resistance: 1562 °F (850 °C) IEC 60695-2-1
- Flame Retardance: V1 UL 94, Requirement 2 NF F 16-101, Requirement 2 NF F 16-102
- Mechanical Robustness: Shocks NO contact 10 Gn for 11 ms IEC 60068-2-27, Shocks NC contact 10 Gn for 11 ms IEC 60068-2-27, Vibrations NO contact 2 Gn, 5...300 Hz IEC 60068-2-6, Vibrations NC contact 2 Gn, 5...300 Hz IEC 60068-2-6
- Warranty: 18 months
Specs
–
| Amperage: | 1.8 |
|---|---|
| Product Type: | Overload Relay |
| Overload Protection: | Thermally |
| Warranty: | 18 Month |
