Starfire SFH-3085W 90,000 BTU Output Oil Boiler w/ Taco Pump

Note: Product Title reflects this boiler's IBR Net Output Rating

The Starfire SFH Oil-Fired Water Boiler features a dependable cast iron heat exchanger and a HydroLevel High Limit and Circulator Relay Control with LWCO.

Exceptional Heat Exchanger Design:
Features a dependable cast iron heat exchanger with cast iron push nipple connections. The sections and push nipples expand at the same rate when heated. By using similar materials instead of less expensive gaskets or steel push nipples, the boiler maintains a water tight seal.

Hydrolevel Operating Control:
Features digital display and diagnostics
Adjusts the water temperature based on your heating system demand which further reduces your heating costs
Built-in low water cut-off (LWCO) to protect the boiler from potentially dangerous low water conditions

Features:

• 5 Sizes are available: 119, 140, 175, 224, 259 MBH Input (CH)
• 20 Year Non-prorated Limited Warranty (Residential)
• Built by American Craftsmen Since 1928

Standard Equipment:

• Boiler Control: Hydrolevel Fuel Smart Hydrostat Control - combination Low
• Water Cut Off with boiler temperature reset and circulator control.
• Heat Exchanger: Cast Iron Heat Exchanger with Cast Iron Push Nipples. Swing out burner door.
• Combustion: Oil burner, target wall/liner.
• Electrical: Wiring Harness, Burner Electrical Disconnect.
• Other: Crated Boiler, Flush Jacket; Circulator 1-1/4”, Temperature Pressure Gauge, Safety Relief Valve, Drain Valve
