MANUALS (4)
Product Highlights
Description
Specs
| Type: | Press Sleeve |
|---|---|
| Size: | 3/8" |
| Material: | Stainless Steel |
| Max Pressure (PSI): | 200 |
| Warranty: | 5 Year |
| Standards Met: | NSF ASTM F1960 ASTM F877 |
| Fitting System Compatibility: | PEX Press |
| Max Temp (F): | 200°F |
| Tubing Compatibility: | FostaPEX PEX |
Questions?
Product Reviews
I would buy this product again and again!
Exceptional service and product as usual
Consistent quality product
Works well
Great price and quality
got what i asked for...
Works Great, very pleased.
Foolproof
Product Q&A
6 QuestionsQ: Why are these being discontinued? Is there an alternative that doesn't throw out the old fitting?
Asked by mike 11 years ago
Add your answer
Verified Reply- SupplyHouse StaffViega PEX Press fittings are now made with the sleeves already inside the fitting. They no longer sell or produce the sleeves separately.
Q: I'm tying into existing fostapex tubing. With the viega pex press, and pex press fittings, is it necessary to use the fostapex prep tool to remove the aluminum sheathing before making the connection, or is it safe to install the sleeves directly over the alluminum? Thanks for any feedback.
Asked by Garrett 12 years ago
Add your answer
Have to strip the aluminum for sure, otherwise it will leak! Sent from my iPhone
You must use the aluminum sheathing tool as the sleeve won't fit. Sent from my iPhone
You have to strip off the aluminum sheathing. I use the Fostapex Prep Tool and it works great.
Q: i have a nibco tool for nibco sleeves they look the same im having a hard time finding the nibco brand will these work?
Asked by nico 14 years ago
Add your answer
Verified Reply- PexSupply StaffThe Viega PexPress system was designed for use with Viega components. The system was only tested together with Viega products and not other manufacturers. Looking at NIBCO sleeves they do share a resemblance, however the NIBCO fittings look different then the Viega fittings for PexPress stainless sleeves. And by combining manufacturers you would not bare a warranty.
Q: With these sleeves what are the couplings that go with this for 1/2" pex-AL-pex . would it be 1/2pex-x1/2 brass coupling ? James
Asked by James 15 years ago
Add your answer
Verified Reply- PexSupply StaffThis fitting system will only work with standard PEX and FostaPEX. It will not work with standard PEX-AL-PEX.
Q: Is special Pex tubing required to use Pex press sleeves?
Asked by 16 years ago
Add your answer
Verified Reply- PexSupply StaffNo, you can use any standard PEX tubing.
No. Just the special press sleeve tool.
Q: Do these rings work with the propress tools?
Asked by Mike 16 years ago
Add your answer
Verified Reply- PexSupply StaffThese rings will not work with the ProPress tools because the tools are intended to make a copper connection where these rings are intended for a PEX connection. The rings required to work with the ProPress tools come on the actual ProPress fittings.
