1-1/4" N241X5 T&P Lead Free Relief Valve w/ Flood Sensor Connectivity (150 psi)
Hover image to zoom

1-1/4" N241X5 T&P Lead Free Relief Valve w/ Flood Sensor Connectivity (150 psi)

Brand:
Watts
SKU:
F121592
Rating:
(0)
Q&A:
(0)
1-1/4" N241X5 T&P Lead Free Relief Valve w/ Flood Sensor Connectivity (150 psi)
Hover image to zoom
$1,605.43 each
Backorder
Backorder
Get it Mon, Apr 1 - Mon, Apr 29
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days

Product Highlights

Size icon
1-1/4"
Inlet Type icon
MNPT
Outlet Type icon
FNPT
Pressure Set Point icon
150 psi
Material icon
Bronze
Lead Free icon
Yes

Description

This lead free automatic reseating temperature and pressure relief valve has a 1-1/4 inch NPT male inlet, 1 inch NPT female outlet, 5 inch stainless steel extension thermostat, pressure relief setpoint of 150 psi, and temperature relief setpoint of 210 degrees F. This valve can be installed in hot water outlet within the allowable distance from the top of the tank for commercial applications to provide protection for hot water supply tanks and hot water heaters. It features a lead free copper silicon alloy body, tamper resistant bonnet screws, and test lever. Includes a nonrestrictive discharge drain line flood sensor with SentryPlus Alert® technology to detect excessive water discharges from the relief valve. Sensor activation requires purchase of an activation kit which can be connected to existing building management systems or the Watts Cellular Gateway.

Features:
  • Features a flood sensor with SentryPlus Alert technology to detect excessive water discharges from the relief valve
  • Requires purchase of activation kit to activate sensor
  • Lead free copper silicon alloy body
  • Tamper resistant bonnet screws
  • 5 Inch thermostat length
  • Non-mechanical seat to disc alignment
  • Set pressure 150 psi
Specifications:
  • Body Material: Lead Free Copper Silicon Alloy
  • GPM-When Relieved: Does Not Apply to Product
  • Inlet Connection Size: 1 1/4 IN
  • Inlet Connection Type: Male Threaded
  • Inlet Thread Type: NPTF
  • Lead Free: YES
  • Maximum Temperature-Fahrenheit: 210
  • Maximum Working Pressure-PSI: 112
  • Outlet Connection Size: 1-1/4 IN
  • Outlet Connection Type: Female Threaded
  • Outlet Thread Type: NPTF
  • Pressure Range: Does Not Apply To Product
  • Pressure Relief Setting-PSI: 150
  • Protection Type : Temperature And Pressure
  • Series: LFN240
  • Shank Length: Does Not Apply To Product
  • Temperature Relief-Fahrenheit: 210
  • Thermostat Material: Stainless Steel
  • Thermostat Probe Length: 5 IN

Specs

Size:

1-1/4"

Thermostat Length:

5"

CSA Rating (BTU/HR):

730000

ASME Rating (BTU/HR):

4059000

Material:

Bronze

Inlet Type:

MNPT

Outlet Type:

FNPT

Pressure Set Point:

150 psi

Lead Free:

Yes
