Description
Features:
  • Designed for Hot Surface and Direct Spark Ignition systems and features a compact footprint and versatile range
  • Slow open, modulating models.
  • Electric on-off switch and convenient quick connect coil terminals and built-in pressure taps
  • Tamper resistant screws and controlled gasket compression to withstand high inlet pressures
  • Mounts in any position including upside down

Specifications:
  • Voltage 24 Vac 50/60Hz
  • Opening Style Modulating
  • Pipe Size 1/2” X 1/2”
  • Regulator Setting 3.5”
  • Regulator Adjustment Range 0.4”-4.0”, Nat. Gas
  • Regulator Adjustment Range 1.3”-11.5”, LP Gas
  • LPConversion Kit Included Yes
  • Reducer Bushing Kit Yes
  • Flow Direction Straight Through
  • Side Taps No
  • Inlet/Outlet Pressure Tap Yes/Yes
  • Standing Pilot with Line Interrupter No
  • HSI/DSI Yes
  • Intermittent/Proven Pilot No
Read more
Manuals (1)
Specs
Fuel Type:
Propane
Voltage:
24v
×
