Fitting System Compatibility: | Push Fit (Sharkbite) Clamp Expander (ProPEX) Crimp PEX Press (Viega) PEX Compression |
---|---|
Size: | 1" |
Material: | PEX |
R-Value: | 3.4 |
Grade: | PEX-a |
Shape: | Coil |
Insulation Material: | Multi-layered Closed Cell Cross-linked Polyethylene Foam |
Heat Loss: | 9.7 BTU/h/ft2 (at 70° Delta T) |
Insulation Thickness: | 1/2" |
Outside Diameter: | 2.27" |
Length (Feet): | 100' |
Coil Size (OD x Width): | 34.50" x 13.75" |
Tubing Type: | Non-Oxygen Barrier Pre-Insulated |
Max Temp (F): | 200°F |
Hydrostatic Ratings: | 200°F (93°C) at 80 psi, 180°F (82°C) at 100 psi, 73.4°F (23°C) at 160 psi |
Thermal Conductivity: | 0.250 Btu.in/sqft.h.degF |
Linear Expansion Rate: | 1.10"/10°F (12°C)/100' |
Warranty: | 25 Year |
Application: | Plumbing |
