Form 9, 1" Threaded TB Type Rigid Conduit Body with Cover & Gasket - Aluminum
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$33.81 each
In Stock
Get 1 Fri, Jul 10 - Mon, Jul 13
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
Threaded Connection
1"
Aluminum
Description
–
This item is a Form 9, 1" Threaded TB Type Rigid Conduit Body with Cover & Gasket - Aluminum manufactured by Appleton.
Features:
Features:
- Conduit outlet body
- access opening back
- configuration tb
- cover type natural stamped copper free aluminum
- hub location tee
- number of hubs 3
- hub size 1 inch
- size 6.59 inch length x 1.75 inch width x 3.03 inch height
- installation threaded
- material epoxy powder coated copper free aluminum body, stainless steel cover screw, neoprene gasket
- form type form 9
- approval ul 514a/b, csa c22.2
- used on imc/rigid conduit
- capacity 16.5 cubic inch
- applicable standard nema fb-1Roomy Interiors, Deep Body Cavity Provides Increased Volume Allowing Higher Wiring Capacity
- Smooth, Rounded Integral Bushings in Hubs Protect Conductor Insulation
- Accurately Tapped, Tapered Threads for Tight, Rigid Joints and Excellent Ground Continuity
- Completely Interchangeable with Crouse-Hinds Mark 9 Bodies, Gaskets and Covers, Equivalent FM9 and Mark 9 Units have Identical Applications and Installation Dimensions
- Aluminum Unilets, Produced from a High-Strength Copper Free Aluminum Alloy, For Light Weight and High Corrosion Resistance
- FM9 Covers with Integral Gasket are Approved for Use in Wet Locations
- Covers are Domed for Extra Wiring Space
- Smooth Hub Bushings and Cover Openings Protect Conductor Insulation
- Smooth Hub Openings Allow Easy Conduit Joining
- Stainless Steel Pan-Head Cover Screws Secure Cover to Body and Provide Superior Screwdriver Seating and Torque
- Hub Size, Body Style, Compliance Data, Maximum Wire Number/Size and Cubic Capacity Molded into Body
- Serve as Pulling Fitting, Make Bends in Conduit System, Provide Openings for Splicing, Connect and Change Direction of Conduit Runs, Allow Connections for Branch Runs, Permit Access to Conductors for Maintenance
Specs
–
| Connection Type: | Threaded |
|---|---|
| Size: | 1" |
| Material: | Aluminum |
| Product Type: | Conduit Body |
