Product Highlights
–
180, 130 CFM
Ceiling, Wall
Description
–
Features:
When properly installed and set, this unit is:
- High efficiency ECM motor
- Constant airflow blower designed to maintain the selected airflow in standard installations
- Silent ventilation with balanced metalic dual inlet blower wheel
- Motorized damper
- Blower efficiency as high as 9.7 CFM/W
- Protection grill for blower
- Learns from the AHU’s operation patterns and the climate variations to provide optimal efficiency
- Eight operation modes: 3 code-compliant modes and 5 comfort and energy-saving modes
- Temperature and humidity sensor
- Temperature and humidity limit settings
- Two possible speeds at set up (130 & 180 CFM)
- Offers the greatest reduction of HERS score compared to CIF solutions or PSC motors
- High density EPS Insulated housing
- Metal housing
- Filtration
- Robust design
- Unequaled installation flexibility: stand alone or combined to an AHU; ceiling hung, attic, flush to ceiling, ceiling mounted, wall mounted
- Paintable door and frame
- Compact and designed to fit between 12-in. c.c. joists
- 6-in. diameter ports with integrated test ports and bumps to maintain tie-trap in place
- 6-ft power cord
- Easy maintenance : can be done within 5 minutes through the access door
- Powered from AHU 24 VAC (R,C) (or low voltage transformer)
- Connected to thermostat (W, Y, G)
- VT11W Wall Control that off ers an ON/OFF function and a filter maintenance reminder
- 9.25" x 9.25" x 2" MERV 8 fi lter
- .25" x 9.25" x 2" MERV 13 fi lter
- Paintable decorative finishing ring for discreet installation
- The BROAN™ Fresh In Premium is protected by a 5-year warranty on parts only
- HVI certifi ed
- ASHRAE 62.2 2010, 2016, IRC/IMC compliant
- ETL Listed. Conforms to UL 507
- Exceeds the ENERGY STAR requirements for Inline Fans
Specs
–
| Product Type: | Fan |
|---|---|
| Mount: | Ceiling Wall |
| Motor: | ECM |
| Air Flow Capacity (CFM): | 180 130 |
| Fan Type: | MERV 13 MERV 8 |
| Min. Operating Temp: | 14°F |
