MANUALS (2)
Product Highlights
Description
- Gas technology - fastest and most precise temperature control
- Highest-class Control Accuracy (CA 0.2 K) per amended EN215 standards
- Danfoss RA Click mount - fast, save, tool-less
- Modern and user-friendly design
- Easy to operate, easy to clean
- Facilities designed for the visually impaired
- Tactile feedback every 0.9°F (0.5°C), for precise temperature setting and improved user experience
- Facilities for limiting and locking temperature set-point, also available as accessory
- Frost protection setting
- A theft protection, from factory or available as accessory
Specs
| Application: | Accessory |
|---|---|
| Sensor Type: | Built-In |
| Temperature Range (F): | 45°F to 86°F |
| Mount: | Direct |
| Used With: | RA 2000 Valves |
Questions?
Product Reviews
Great price
Quality Product
i will buy product again, good pricing quick shipment
Works Well
Great quality product
Great product!
I did buy this product twice!
Just what I needed
We now have heat on the other side of our building.
I would use this company again.
Product Q&A
5 QuestionsQ: will this work to manualy adjust a 3/4" NPT angle valve part # RA 2000
Asked by dj 11 years ago
Add your answer
Verified Reply- Supplyhouse StaffYes it will.
Q: IS THIS DIRECT MOUNT OPERATOR FOR THE 013G0140 DANFOSS VALVE? IF YES, THEN HOW DOES THE 013G0140 CONTROL THE TEMPERATURE WITHOUT THIS OPERATOR?
Asked by PETER MARREN 13 years ago
Add your answer
The valve comes with a small gray adjustment knob that you can use to manually adjust the temperature. The controller replaces the basic knob and adjusts the temperature automatically. The valve in the room with the thermostat must use the basic knob, and the other rooms can take either type - but the automatic type is the real key to the system "self-balancing" the temperature in each room.
I believe the operator is required to set the temp.
The valve provides the mechanical mechanism to shut off the water supply - but the operator senses the temperature and operates the valve. One is useless without the other. Gavin Eyre
I looked at the supplied link at the install instructions and this valve will work. This is the link: http://s3.pexsupply.com/manuals/***.****03/44329_PROD_FILE.pdf The quality on the valve and operator is top notch. I have had them installed for 3 years and they are still working great.
Without this operator the 013G0140 valve acts the same as a manual valve. It never shuts off when the desired temp is reached. It just keeps putting out heat, add this operator and it will turn off when set temp is reached and turn back on when room temp goes below set temp.
It controls the temperature well as long as the valve is not enclosed inside a radiator cover. If this is the case, you need a remote actuator.
Q: please let me know how to properly install product
Asked by super 15 years ago
Add your answer
Verified Reply- PexSupply StaffHere is a link to the installation manual: http://s3.pexsupply.com/manuals/1296058950009/45300_PROD_FILE.pdf
You just twist the base of the knob and it slides right on the valve body. It can be positioned in two orientations which are 180 degrees apart so that you can always see the numbers on the dial to know what temperature you are setting the radiator to.
Q: can these be used on steam one pipe systems and mounted upright by just removing the value handles and replacing it ?
Asked by glen 15 years ago
Add your answer
Verified Reply- PexSupply StaffYes. This product can be used as you described.
Q: I am a property manager and have an apartment building with 150 or so danfoss TRV's in 26 residential units. Each year a radiator or two will not shut off and provides constant heat whike the boiler is running. The TRVs are only 4 or so years old, is there a way to clean them out or do I need to replace the head or part of the head? Is there any regular maintenance that needs to be done on these heads? Thanks
Asked by Zac 16 years ago
Add your answer
Verified Reply- PexSupply StaffThere is no maintenance that needs to be done for this product. Just check to make sure they are all tight because of the spring inside.
