Description
Product Features
  • Internal factory-installed thermal expansion valves for cooling and heat pump applications
  • Direct drive, multi-speed ECM blower motor
  • All-aluminum evaporator coil
  • Coil mounting track for quick repositioning
  • Optimized for use with R-410A refrigerant
  • Cabinet air leakage less than 2.0% at 1.0 inch H2O when tested in accordance with ASHRAE standard 193
  • Cabinet air leakage less than 1.4% at 0.5 inch H2O when tested in accordance with ASHRAE standard 193
  • AHRI certified; ETL listed
  • Rigid SmartFrame™ cabinet
  • Horizontal or vertical configuration capabilities
  • 21" depth for easier attic access
  • DecaBDE-free thermoplastic drain pan with secondary drain connections
  • Screw-less sides and back helps to reduce condensation when installed in humid locations
  • Foil-faced insulation covers the internal casing to reduce cabinet condensation
  • Galvanized, leather grain-embossed finish
  • Glue-less cabinet insulation retention
  • Tool-less filter access
  • Field Installed 3 kW – 25 kW electric heater kits available
Read more
Manuals (3)
Specs
Application:
HVAC
Airflow:
Multi-Position
Type:
Multi-Speed
Cooling Capacity (BTU):
42000
Max Airflow (CFM):
1720
Min Airflow (CFM):
620
Ton:
3.5
Voltage:
230v
208v
Suction Line:
7/8"
Liquid Line:
3/8"
Weight (lbs):
155 lbs
Horse Power:
3/4
Warranty:
10 Year Parts
×
