T451A3005 has been discontinued
Discontinued June 8, 2022
This product was discontinued by the manufacturer.
MANUALS (1)
Direct Replacement:
3-Speed Fan Coil Thermostat, 2 or 4 pipe Manual/Auto changeover, Heat/Cool/Auto, 3 speed fan, Supply voltage: 120/240/277 Vac, TB6575C1000
Product Highlights
–
Non-Programmable
277v, 240v, 208V, 120v, Line voltage
Vertical, Horizontal
Hardwired
19, 22 Amps
2°F
Description
–
Note: This light duty line voltage thermostat is for heating only. The brochure lists information for the entire series, not for this specific thermostat.
Light Duty Line Voltage Thermostats control line voltage valves, motors, contractors, electric heat, elements, duct furnaces, and fan coil units.
Product Features
Specifications
Light Duty Line Voltage Thermostats control line voltage valves, motors, contractors, electric heat, elements, duct furnaces, and fan coil units.
Product Features
- Automatic heating anticipation.
- Mount on standard vertical or horizontal outlet box.
Specifications
- Amps (120V): 22
- Amps (208V): 22
- Amps (240V): 22
- Amps (277V): 19
Specs
–
| Application: | Heat Only Electric Heat (Line Voltage) |
|---|---|
| Amperage: | 19 22 |
| Programmability: | Non-Programmable |
| User Interface: | Mechanical |
| Mount: | Vertical Horizontal |
| Power Method: | Hardwired |
| Voltage: | 277v 240v 208V 120v Line voltage |
| Differential: | 2°F |
| Switch: | SPST |
| Frequency: | 60 Hz 50 Hz |
| Color: | Beige |
| Height (Inches): | 4.5" |
| Width: | 2-15/16" |
| Depth (Inches): | 1-1/2" |
