Remote Bulb Refrigeration Temperature Controller with -35 to 30 Celsius setting temperature and 8 ft. capillary
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$294.23 each
In Stock
Get 1 Mon, Jun 29
Order by 6PM, receive Monday
MANUALS (2)
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
SPDT
30°C Max Temp
-35°C Min Temp
Description
–
Provide limit or temperature control in refrigerated areas where remote mounting of sensing element is required.
Product Features:
Product Specifications:
Product Features:
- Liquid-filled copper elements provide rapid sensing to control the compressor system.
- Control temperature in a duct, tank, freezer or cooler.
- Controller element can be directly immersed in the controlled medium.
- Adjustable control setpoint.
- Ambient temperature compensation provides good temperature control.
- Refer to T775 Electronic Remote Temperature Controller where more exact control is required and/or remote controller location is preferred.
Product Specifications:
- Remote Bulb Refrigeration Temperature Controller with -35 C to 30 C setting temperature and 8 ft. capillary
- Type : Remote bulb
- Application: Provides control of cooled or refrigerated space
- Switching: 1 SPDT
- Setting Temperature Range: -35 C to +30 C
- Sensor Element: Copper bulb
- Capillary Length (ft): 8 ft.
- Maximum Operating Temperature (F): 125F
- Differential Temperature (F): 3.5 F
- Differential Temperature (C): 1.9 C to 8.9 C
- Voltage: 120 Vac
- Voltage: 240 Vac
- Contact Ratings (120 Vac): 8.0 AFL, 48.0 ALR
- Contact Ratings (240 Vac): 5.1 AFL, 30.6 ALR
- Dimensions (in.): 5 5/8 in. high x 2 in. wide x 2 1/4 in. deep
- Bulb Size (in): 3/8 in. diameter x 3 in. long
- Comments: Celsius Model
Specs
–
| Capillary Length: | 8' |
|---|---|
| Temperature Range: | -35° to 30°C |
| Max Temp (C): | 30°C |
| Min Temp (C): | -35°C |
| Switch Action: | SPDT |
