12,000 BTU, R-410A, Ductless Multi-Split Air Cond/Heat Pump - Indoor Unit (Compatible w/ Wired Wall Thermostat)
 --%3E %3Csvg version='1.1' id='Fill' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23F15C02' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
' fill='%23F15C02' d='M49 0C21.938 0 0 21.938 0 49s21.938 49 49 49 49-21.938 49-49S76.062 0 49 0m0 82.709a7.54 7.54 0 1 1 0-15.08 7.54 7.54 0 0 1 0 15.08m7.54-28.412a7.541 7.541 0 0 1-15.08 0V22.831a7.54 7.54 0 0 1 15.08 0v31.466z'/%3E%3C/svg%3E)
MANUALS (4)
'/%3E%3C/svg%3E){kind=small}
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Product Highlights
Description
This R410A unit is no longer manufactured as per the AIM Act of 2020. While replacement parts are available for repairs, a new unit will require replacing the entire system to support the new A2L R32 refrigerant.
Please visit our Mini Split Air Conditioners for system selection or reach out to Customer Care Team Contact Us for assistance.
NOTE: Capacities Vary Based on Combinations
Product Features:
- Inverter (Variable Speed Compressor)
- Chaos Wind
- Jet Cool/Jet Heat
- Self-cleaning indoor coil
- Auto operation (artificial intelligence)
- Auto restart operation
- 24-hour on/off timer
- 4-Way Auto Swing
- Sleep mode
- Low ambient operation down to 14ºF (cooling mode)
- Wall unit
- Installation plates & hardware
- Wireless LCD remote control, batteries, holder and holder hardware
- Owner's manual
We recommend the installation of all LG Ductless Split Systems to be done by a licensed, trained & qualified HVAC technician with the proper knowledge and background. A trained technician will be able to judge the best location for the air handling (evaporator) unit and also the correct size for the area it has to cool.
Should you experience an issue during the installation or the initial startup of the unit please do not contact the manufacturer. You should have the technician that installed the units contact us or the manufacturer. LG cannot accept any service or warranty calls from anybody but a licensed HVAC technician. We have a full technical support team available to help you throughout the installation process should the need arise.
Neither we or LG Electronics U.S.A. can be held liable for improper installation and operation of any LG air conditioning product purchased from our company. Should a warranty issue arise where parts will need to be replaced, an installation receipt will be required along with your sales receipt. Failure to provide a receipt or invoice may result in the warranty not being honored.
Note: Warranties on mini split air conditioners only include parts and do not include labor. The licensed HVAC Technician who installs your air conditioner should always provide you with a labor warranty (preferably for a full year to compliment the manufacturers' parts warranty).
Specs
| Max. Pipe Length (ft.): | 82' |
|---|---|
| Type: | Multi-Split |
| Product Type: | Indoor Unit |
| Heating Capacity (BTU): | 12000 |
| Cooling Capacity (BTU): | 12000 |
| Energy Star Rated: | Yes |
| Number of Zones: | 1 |
| Dehumidification (Pts/Hr): | 2.5 |
| Application: | Cooling |
| Air Circulation (CFM H/M/L): | 336/318/300 |
| Sound Level H/M/L (dB(A)+3): | 39/36/31 |
| Running Current (A): | 0.15 |
| Voltage: | 208/230V |
| Phase: | 1 |
| Hertz: | 60 |
| Liquid Line: | 1/4" |
| Gas Connection: | 3/8" |
| Drain OD: | 27/32" |
| Drain ID: | 5/8" |
| Refrigerant Type: | R-410A |
| Sensor Type: | Thermistor |
| Indoor Dimensions (H x W x D): | 11-7/32" x 35-1/4" x 8-9/32" |
| Indoor Weight: | 24.5 lbs |
| Warranty: | 5 Year Compressor/2 Year Parts |
| Mount: | Wall |
Questions?
You May Also Need
44 Replacement Parts
Need help finding a replacement part?
Product Reviews
good product
Product Q&A
3 QuestionsQ: Does this come with the installation kit?
Asked by Maggie 14 years ago
Add your answer
Verified Reply- PexSupply StaffIt comes with a mounting bracket and other miscellaneous installation items, but this is only the indoor unit of a multi-split system. You'd also need at least one other indoor unit, a proper outdoor unit, refrigerant line-sets, and electrical wires/power in order for the system to function.
no,purchase seperatley,or at a local hvac supplier,thats what we do
I don't recall..but the unit works great and is super efficient....i think it did come with "stuff" in it...wires-remote-etc....
Q: Hi, Do you need to have the wired thermostat to control the unit or can you just use the remote?
Asked by GW 15 years ago
Add your answer
Verified Reply- PexSupply StaffThe remote can control this unit (the wired thermostat is optional). It also must be connected to an appropriate outdoor unit with a refrigerant line-set and the proper electrical wiring. Multi-Split systems require at least two indoor units to operate.
Q: do you have to have a outside unit
Asked by 15 years ago
Add your answer
Verified Reply- PexSupply StaffYes, all indoor mini-split units must be connected to an outdoor mini-split unit in order to function properly.
yes
