Normally Closed, 2 Amp Fixed Current Sensor Relay (24-240V)

The TCS Series is a low cost method of go/no go current detection. It includes a solid-state output to sink or source current when connected directly to a standard PLC digital input module. Its normally open or normally closed output can also be used to control relays, lamps, valves, and small heaters rated up to 1A steady, 10A inrush. The TCS is self-powered (no external power required to operate the unit) and available with an adjustable actuation range of 2 - 20A or factory fixed actuation points from 2 - 45A.

Product Features

• Self powered: No control voltage is required to operate the unit
• Totally solid state and encapsulated: No moving parts to arc and wear out over time and encapsulated to protect against shock, vibration, and humidity
• Can connect directly to PLC: Solid state output to sink or source current can be connected directly to a standard PLC digital input module
• 1A steady, 10A inrush solid-state output: Provides 100 million operations in typical conditions
• Complete isolation between sensed current and control circuit: Allows you to monitor a load in a separate electrical system
