Close-Coupled Pump Motor - 3 HP, 1760 RPM, 3 PH (230/460V)

Brand:
Marathon Motors
SKU:
E148B
Rating:
(0)
Q&A:
(0)
Close-Coupled Pump Motor - 3 HP, 1760 RPM, 3 PH (230/460V)
Magnifying glass
Hover image to zoom
$686.64 each
In Stock
In Stock
Get 1 Wed, Jul 8
This item replaces: E148A
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days

Product Highlights

–
Product Highlight: Voltage
230/460v
Product Highlight: RPM
1760 RPM
Product Highlight: Rotation
Reversible
Product Highlight: Horse Power
3 HP
Product Highlight: Mount
Round
Product Highlight: Amperage
8 Amps

Description

–
Close-Coupled Pump Motor - 3 HP, 1800 RPM, 3 PH (230/460V)

Features:
  • NEMA JM pump shaft dimensions
  • JMV frame includes drip cover for vertical mount without base
  • JM frame has rigid base, drip cover included
  • Mechanically locked on shaft end
  • Continuous duty
  • F1 mounting only, cannot reassemble to F2

Specs

–
Type:

Close-Coupled Pump

RPM:

1760

Amperage:

8

Horse Power:

3

Voltage:

230/460v

Phase:

3

Frame:

182JMV

Mount:

Round

Bearings:

Ball

Rotation:

Reversible

Enclosure Type:

Drip Proof

Motor:

Squirrel Cage Induction Run

Duty:

Continuous

Poles:

4

Speeds:

1

Max Ambient Temp (°F):

104°F

Insulation Class:

F

Overload Protection:

None

Motor Orientation:

Vertical Shaft Down
