General Purpose Motor - 1-1/2 HP, 3600 RPM, 3 PH (208-230/460V)
$422.54 each
In Stock
Get 1 Mon, Feb 13
MANUALS (1)
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
230/460v
3515 RPM
Reversible
1-1/2 HP
Resilient Base
4.0/2.0 Amps
Description
–
General Purpose Motor - 1-1/2 HP, 3600 RPM, 3 PH (208-230/460V)
Features:
***Note: Image may not be actual representation of item.
Features:
- Meets or exceeds NEMA Premium® efficiencies NEMA Premium® models are in compliance with EISA2007
- Cast iron frame and brackets
- Inverter Duty 10:1 Variable Torque and 10:1 Constant Torque, 1.0 SF (except as noted)
- 1.15 Service Factor
- Class F Insulation
- Standard assembly F1, reversible to F2 assembly
- UL Recognized, CSA Certified, CE Mark
- Three year warranty
***Note: Image may not be actual representation of item.
Specs
–
| Type: | General Purpose |
|---|---|
| RPM: | 3515 |
| Amperage: | 4.0/2.0 |
| Horse Power: | 1-1/2 |
| Voltage: | 230/460v |
| Phase: | 3 |
| Frame: | 143TC |
| Mount: | Resilient Base |
| Bearings: | Ball |
| Rotation: | Reversible |
| Enclosure Type: | Totally Enclosed Fan-Cooled (TEFC) |
| Motor: | Squirrel Cage Induction Run |
| Poles: | 2 |
| Duty: | Continuous |
| Speeds: | 1 |
| Max Ambient Temp (°F): | 104°F |
| Insulation Class: | F |
| Overload Protection: | None |
| Motor Orientation: | Horizontal |
