2-Wire, Compact Horn Strobe, Wall (White), P2GWKLED-P
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Description
The System Sensor L-Series Outdoor and L-Series with
LED Outdoor platforms offer the most versatile and easy-to-use
line of Weatherproof Horns, Horn Strobes, and Strobes that can meet
virtually any application requirement, including indoor, outdoor, wet,
dry, and washdown environment applications in temperatures from
-40°F to 151°F.
The L-Series Outdoor and L-Series with LED Outdoor appliances
are NEMA 4X and IP56 rated without having to seal the backbox.
Additional caulk or sealant are not required on the backbox for a
faster, cleaner installation. The L-Series platform offers a modern
aesthetic across the Indoor and Outdoor platform and design
variations across applications: wall or ceiling mount, red or white
color choices, LED colored lenses for distinctive visual signaling.
In addition, installers can easily adjust appliances through field
selectable candela, tone, and volume selections using rotary
switches.
LED technology offers significantly lower current draw compared
to older Xenon bulbs across a full candela range. This improves
design flexibility for notification appliance circuits (NACs) while also
reducing power supply requirements allowing for simpler and lower
cost installations. UL listed waterproof wirenuts are provided to make
the connection between the field wiring and the mounting plates.
Outdoor devices ship with plastic back boxes that accommodate
in-and-out wiring for daisy chaining devices. Knock-outs located
on the back eliminate the need to drill holes for screw-in mounting.
Note: When replacing SpectrAlert Advance products, the backbox
should be updated to the L-Series with LED backbox
Features:
- Weatherproof per NEMA 4X, IP56 as a standalone device
- Rated from -40°F to 151°F
- Electrically compatible with Legacy SpectrAlert Advance and
- SpectrAlert devices at 16-33 VDC
- Field-selectable candela settings on wall units: 15, 30, 75, 95,
- 110, 135, and 185
- Field-selectable candela settings on ceiling units: 15, 30, 75, 95,
- 115, 150, and 177
- Rotary switches for candela, horn, and volume
Specs
| Product Type: | Strobe |
|---|
