| Amperage: | 0.67 |
|---|---|
| Material: | Cast Iron |
| Application: | Heating |
| Modes: | 3 |
| Speeds: | Variable |
| Max Pressure (PSI): | 125 |
| Type: | Pump |
| Horse Power: | 1/20 |
| Hertz: | 50/60 |
| RPM: | 1750-3800 |
| Voltage: | 115-230V |
| Max Flow (GPM): | 15 |
| Max Head (Ft): | 15 |
| Temperature Range (F): | 40°F to 230°F |
| Connection Type: | Flanged x Flanged |
Yes this is suitable for a closed loop system. generally stainless steel pumps are used to circulate domestic water. This pump can be used with a line voltage thermostat.
Yes, they can be lengthened with thermostat wire.
Yes, those flanges would work on the Bumblebee.
Either can be used for supply or return. The installation instructions can be found here on our site : http://s3.pexsupply.com/product_files/Taco%20-%20HEC-2%20-%20Install%20Instructions.pdf
No, the HEC-2 is not for use in potable systems, as it is made of cast iron. It should only be used in closed loop heating applications.
There is just a single SKU. The pump can be configured for either voltage.
Yes, the Bumblebee will accommodate standard taco flanges from 3/4" to 1-1/2".
