1" LF800M4-FR-FZ Lead Free Freeze Resistant Anti-Siphon Vacuum Breaker w/ Freeze Sensor Connectivity
 --%3E %3Csvg version='1.1' id='Fill' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23F15C02' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
MANUALS (3)
This item replaces: 0792018
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
1"
Yes
Copper Silicon Alloy
150 MAX PSI
Female Threaded Connection
15 PSI
Description
–
his 1" lead free anti-siphon pressure vacuum breaker backflow preventer prevents the reverse flow of polluted water from entering into the potable water supply due to backsiphonage. It consists of a lead free bronze body construction silicone rubber check valve disc, plastic check valve seat, stainless steel springs, a bonnet with silicone rubber O-ring seal, a lightweight plastic disc float, tee handle shutoff, and test cocks for winterization draining. It is ideal in health hazard continuous pressure applications such as irrigation systems and industrial process water systems where the water enters the equipment at or below its flood rim. The maximum pressure is 150 psi (10.3 bar) and the minimum pressure is 15 psi (55 kPa). The pressure vacuum breaker includes a freeze sensor for use with SentryPlus Alert® technology to signal when ambient temperature approaches the freeze threshold. Activated through an add-on connection kit, the sensor also triggers freeze alerts to facility personnel. Sensor activation requires purchase of an activation kit which can be connected to existing building and irrigation management systems.
Specifications:
Specifications:
- Body Material: Lead Free Copper Silicon Alloy
- Inlet Connection Size: 1"
- Inlet Connection Type: Female Threaded
- Inlet Shutoff Valve Type: Quarter Turn Ball Valve
- Inlet Thread Type: NPT
- Lead Free: Yes
- Maximum Temperature-Fahrenheit: 140
- Maximum Working Pressure-PSI: 150
- Outlet Connection Size: 1"
- Outlet Connection Type: Female Threaded
- Outlet Shutoff Valve Type: Quarter Turn Ball Valve
- Outlet Thread Type: NPT
- Pressure Operation: Continuous
- Protection Type: Backsiphonage
- Series: LF800M4FR
Specs
–
| Features: | Freeze Sensor Connectivity |
|---|---|
| Application: | Plumbing |
| Size: | 1" |
| Material: | Copper Silicon Alloy |
| Min Pressure (PSI): | 15 |
| Max Pressure (PSI): | 150 |
| Max Temp (F): | 140°F |
| Product Type: | Vacuum Breaker |
| Lead Free: | Yes |
| Connection Type: | Female Threaded |
