Description
Features
- A High temperature submersible pump series with electrical components meeting the National Electrical Code requirements for 200° F service
- Comprehensive line of models, styles and modes
- Conduit length is 3 feet for automatic models and 6 feet for nonautomatic models
- Power cord length is 15 feet for automatic models and supplied by others for nonautomatic models
- High temperature liquid-tight conduit used with high temperature cable
- High temperature motor windings
- High temperature Viton® gaskets
- High temperature thermal overload protected
- All control components in contact with the water are high temperature rated
- All models have vortex impeller design
- All models have stainless steel screws, guards, handles and control arm & seal assemblies
- Float operated mechanical switch box which is mounted on the discharge pipe above the operating level (Switch box is not intended to come in continuous contact with 200° F water)
- Mechanical seal has NI-Resist rotary face and Viton® elastomer
- Corrosion-resistant powder coated epoxy finish
