160,000 BTU ATHR-160M Adapt Premium Condensing Ultra-Low NOx Tankless Water Heater (Natural Gas)

Brand:
AO Smith
SKU:
ATHR-160M
Rating:
(0)
Q&A:
(0)
160,000 BTU ATHR-160M Adapt Premium Condensing Ultra-Low NOx Tankless Water Heater (Natural Gas)
Magnifying glass
Hover image to zoom
$1,738.55 each
In Stock
In Stock
Get 23 Mon, Jul 6 - Wed, Jul 8

Lift Gate

This product weighs 125 lbs. and may require the use of a lift gate. If you do require a lift gate at your delivery, you'll have the option to add this FREE of charge when you checkout.
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days

Product Highlights

Product Highlight: Fuel Type
Natural Gas
Product Highlight: Max Flow (GPM)
10.5 MAX GPM
Product Highlight: Installation Type
Indoor Only
Product Highlight: Width (Inches)
16-1/2" Width
Product Highlight: Depth (Inches)
16-1/10" Depth
Product Highlight: Energy Star Rated
Yes

Description

This unit is NOT approved for installation in Manufacture Homes and is not suitable for space heating applications only.

A.O. Smith's ADAPT premium condensing gas tankless water heaters deliver robust, on-demand performance and the flexibility to install in practically any residential setting. Easily add scale prevention protection by replacing the bypass cartridge with an optional X3 cartridge sold separately - which can make the heat exchanger last up to three times longer than a standard tankless water heater while maintaining like-new performance. The ADAPT line features a built-in Control Display for setting and reviewing up to two recirculating schedules; as well as checking heater status and error codes. Manage temperature settings and activate the heater and recirculation remotely with optional kits (sold separately). All models are ENERGY STAR certified and extremely efficient with a Uniform Energy Factor of 0.95 and also comply with Ultra-Low NOx regulations. All ADAPT models are field convertible from Natural Gas to Liquid Propane, kit included, and can be installed indoors or outdoors (with an Outdoor Vent Cap Kit sold separately). Cascade up to 12 like heaters together for larger applications requiring multiple water heaters to work in conjunction, cable included.

Specs

Width (Inches):

16-1/2"

ASME:

No

Cold Water Inlet (NPTM):

3/4"

Depth (Inches):

16-1/10"

Installation Type:

Indoor Only

Energy Star Rated:

Yes

Hot Water Outlet (NPTF):

3/4"

Gas Connection:

1/2"

Energy Factor:

0.95

Voltage:

120v

Weight (lbs):

104 lbs

Min Temp (F):

100°F

Frequency:

50-60 Hz

Height (Inches):

33-4/5"

Max Temp (F):

140°F

Fuel Type:

Natural Gas

Type:

Condensing

Hertz:

60

50

Application:

Residential

BTU (Min):

9000

Connection Size:

3/4"

Max Flow (GPM):

10.5

Water Connection:

3/4"

Product Type:

Tankless Heater

BTU (Max):

160000

Vent Type:

Power Vent

Direct Vent

Features:

Ultra Low NOx

Max Pressure (PSI):

150

Vent Size:

3"

Amperage:

5

Connection Type:

FNPT
