15 lb-in Positive Positioning Damper Actuator (120V)

The MP-5400 Series Actuators are for electronic proportional control of dampers, valves, or program switches which require the return to normal position upon power interruption. This series is compatible with 2 to 15 Vdc input signals from TAC System 8000, TAC NETWORK 8000, and TAC DMS DDC controllers.

Features

• Proportional actuators controlled by variable Vdc input signal
• Positive positioning
• Spring return
• Fixed 3 Vdc operating span.
• Adjustable 2 to 12 Vdc start point for paralleling or sequencing of actuators.
• 10,000 ohm or greater input impedance.
• 24 Vac, 120 Vac, and 240 Vac models.
• Available in damper models or base models that require damper or valve linkage.
• Die cast lower housing and painted steel upper housing
• Hydraulic actuator with oil-immersed motor, transducer, and pump.
