Description
–
Specifications:
- Power Supply: 100...240 VAC, -15% / +10%, 50/60 Hz
- Power consumption in operation: 2.5 W
- Power consumption in rest position: 1.3 W
- Transformer sizing: 5 VA (class 2 power source)
- Electrical Connection (2) 18 GA appliance cables with 1/2" conduit connectors, 3 ft [1 m],
- Overload Protection electronic throughout 0° to 95° rotation
- Position Feedback: No Feedback
- Angle of rotation: Max. 95°, 90°
- Direction of rotation motor: reversible with CW/CCW mounting
- Direction of motion fail-safe: reversible with CW/CCW mounting
- Position indication: Mechanical
- Running Time (Motor): <75 s
- Running time fail-safe: <75 s
- Ambient humidity: max. 95% r.H., non-condensing
- Ambient temperature: -22...122°F [-30...50°C]
- Storage temperature: -40...176°F [-40...80°C]
- Degree of Protection: IP54, NEMA 2, UL Enclosure Type 2
- Housing material: UL94-5VA
- Agency Listing: cULus acc. to UL60730-1A/-2-14, CAN/CSA E60730-1:02, CE acc. to 2004/108/EC
- Noise level, motor: 50 dB(A)
- Noise level, fail-safe: 50 dB(A)
- Maintenance: maintenance-free
- Quality Standard: ISO 9001
- Weight: 1.8 lb [0.80 kg]
- Auxiliary switch:1 x SPDT, 3 A resistive (0.5 A inductive) @ AC 250 V, adjustable 0...95°
Specs
–
| Power Supply: | 100 to 240 VAC |
|---|---|
| Fail Safe Mode: | Spring Return |
| Actuator Type: | On/Off |
| Ambient Temperature: | -22°F to +122°F |
