35316 has been discontinued
Discontinued January 14, 2023
This product was discontinued by the manufacturer.
MANUALS (3)
'/%3E%3C/svg%3E){kind=small}
Direct Replacement:
 --%3E %3Csvg version='1.1' id='Half' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cg%3E %3Cpath fill='%23F15C02' d='M30.05,70.23l3.79-12.01L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1h1.58 L93.71,7.18c-3.58-3.82-8.66-6.23-14.28-6.23H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,5.41,2.22,10.32,5.79,13.88 L30.05,70.23z'/%3E %3C/g%3E %3Cpath fill='%23FBC8B4' d='M93.71,7.18L60.98,39.6H91.2L65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82l5.55-17.59L6.75,93.32 c3.55,3.54,8.44,5.73,13.82,5.73h58.87c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,15.4,97.01,10.69,93.71,7.18z'/%3E %3C/svg%3E){kind=small}
Product Highlights
–
1600 CFM
1 Year Warranty
Gable
120v
3.9 Amps
1420 RPM
Description
–
Trapped attic air can easily reach 150° or more. These units remove super-heated attic air, making any home more comfortable. Whether it's air conditioned or not. In those homes that are, the air conditioners run less and don't have to work nearly as hard. And all BROAN Powered Attic Ventilators are as efficient as they are dependable.
- 14" diameter steel blade specially designed for maximum air movement.
- Operates automatically – adjustable thermostat built-in.
- Thermally protected, permanently lubricated motor.
- Quiet, high-performance operation for inside-the-attic applications
- Galvanized steel housing, ribbed for added strength
- Mounting brackets simplify installation
- 1600 CFM for attics up to 2280 sq. ft.
- Use with BROAN model 433 Automatic Shutter, available separately, or
- Standard HVI Wood Louver
Specs
–
| Product Type: | Attic Ventilator |
|---|---|
| Installation Type: | Gable |
| Voltage: | 120v |
| Amperage: | 3.9 |
| Motor: | Split Capacitor |
| RPM: | 1420 |
| Air Flow Capacity (CFM): | 1600 |
| Warranty: | 1 Year |
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
14 Replacement Parts
Hex Nut - 5/16"-18
SKU: S99260465
BroanScrew - #10-32 x 1/2"
SKU: S99150471
BroanWhiz Nut - 1/4"-20
SKU: S99260477
BroanWiring Box Cover, S98006877
SKU: S98006877
BroanWiring Box, S98009757
SKU: S98009757
BroanHousing Mounting Bracket
SKU: S98005039
BroanHex Cap Screw - 5/16"-18 x 3/4"
SKU: S99170254
BroanSheet Metal Replacement Screw
SKU: S99170245
BroanMotor - Includes Capacitor
SKU: S97015764
BroanScrew - 1/4"-20 x 1/2"
SKU: S99200202
BroanWire Lead Assembly
SKU: S97005329
BroanFan Blade - Includes Set Screw
SKU: S97006971
BroanMotor Mounting Bracket
SKU: S98008298
BroanAdjustable Thermostat
SKU: S97008413
Broan
Need help finding a replacement part?
Fill out the part request form and someone will get back to you shortly.
PART REQUEST FORM
Product Reviews
5 out of 2 reviews
100% would recommend this product
5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%
Showing 1-2 of 2 reviews
Just what I needed
Had a roof mounted ventilator fan go a few weeks ago. Not wanting a complete assembly I found this gable fan was the same size and easily replaced the failed unit. Just simply remove the 3 bolts and wire it in.
