Description
Features:
  • High Start Torque
  • Reversible
  • 40 Degrees C Ambient
  • 60 Hz
  • 3/4 HP
  • 3450 RPM
  • 208-230/115 Volt
  • 4.7-4.6/9.2 Full Load Amps
  • 56 Frame
  • Ball Bearing
  • Service Factor: 1.25
  • Auto Protector
  • Insulation Class B
  • Open D.P. Enclosure
Hide Description
Manuals (1)
Specs
Motor:

Capacitor Start

Type:

Single or Dual Voltage

Capacitor Start

Induction Run

Bearings:

Ball

Horse Power:

3/4

Diameter (Inches):

6-1/2"

Duty:

Continuous

RPM:

3450

Mount:

Cushion Base

Poles:

2

Voltage:

115/208-230v

Phase:

1

Rotation:

RCCW

Hertz:

60

Enclosure Type:

Drip Proof

Frame:

56

Speeds:

1

Amperage:

9.2

4.6

Insulation Class:

B

Amperage:

4.7

4.7-4.6/9.2

Overload Protection:

Thermally

Max Ambient Temp (°F):

104°F

×
