Description
Features:
  • Split Phase Resilient Base Motor
  • Continuous Duty
  • Reversible
  • 1/3 HP
  • 1725 RPM
  • 115/208-230 Volt
  • 6.2/3.2-3.3 Full Load Amps
  • 56Z Frame
  • Ball Bearing
  • Service Factor: 1.35
  • Auto Protector
  • Open Enclosure
Hide Description
Manuals (1)
Specs
Type:

Split Phase

Horse Power:

1/3

Diameter (Inches):

5-5/8"

Bearings:

Ball

Voltage:

230v

115/208-230v

Duty:

Continuous

Rotation:

Reversible

Mount:

Resilient Base

Poles:

4

RPM:

1725

Phase:

1

Enclosure Type:

Open

Hertz:

60

Speeds:

1

Frame:

56Z

Amperage:

6.0/2.7-3.0

Insulation Class:

B

Amperage:

2.7

3

6

Overload Protection:

Automatic

Max Ambient Temp (°F):

104°F

×
