Description
Features:
  • Auto Protector
  • Class B Moisture-Resistant Insulation
  • Double Sealed Ball Bearing
  • Permanent Split Capacitor
  • Positioning Lugs for easy Belly-Band Mounting
  • Quick-Connect Design
  • Reversible
  • Service Factor 1.0
  • 60 Degrees C Ambient
  • Supplied with resilient mounting rings
Hide Description
Manuals (1)
Specs
Type:

Permanent Split Capacitor

Single or Dual Voltage

Horse Power:

1/2

Voltage:

115/208-230v

RPM:

850

Duty:

Continuous

Bearings:

Double Sealed Ball

Mount:

Resilient Base

Poles:

8

Enclosure Type:

Open Air Over

Rotation:

RCW

Hertz:

60

Phase:

1

Speeds:

1

Frame:

56Y

Amperage:

6.6/4.0-3.3

Insulation Class:

B

Overload Protection:

Thermally

Diameter (Inches):

6-1/2"

Max Ambient Temp (°F):

140°F

×
