OCA3076H has been discontinued
Discontinued October 16, 2025
This product was discontinued by the manufacturer.
MANUALS (1)
Suggested Alternative:
Product Highlights
–
460v
1140 RPM
Reversible
3/4 HP
Extended Studs
1.9 Amps
Specs
–
| Type: | 3 Phase |
|---|---|
| OEM: | BDP Carrier |
| Horse Power: | 3/4 |
| Voltage: | 460v |
| Duty: | Air Over |
| Mount: | Extended Studs |
| RPM: | 1140 |
| Bearings: | Ball |
| Poles: | 6 |
| Speeds: | 1 |
| Enclosure Type: | Totally Enclosed |
| Rotation: | Reversible |
| Hertz: | 60 |
| Phase: | 3 |
| Amperage: | 1.9 |
| Frame: | 48Y |
| Insulation Class: | B |
| Overload Protection: | Automatic |
| Max Ambient Temp (°F): | 140°F |
| Motor Orientation: | Vertical Shaft Down |
