OTR4513 has been discontinued
Discontinued June 9, 2022
This product was discontinued by the manufacturer.
MANUALS (1)
Direct Replacement:
Product Highlights
–
208-240V
1550 RPM
CCWLE
1/8 HP
Extended Studs
0.9 Amps
Specs
–
| Type: | Permanent Split Capacitor |
|---|---|
| OEM: | Trane |
| Voltage: | 208-240V |
| Horse Power: | 1/8 |
| Duty: | Air Over |
| Bearings: | Sleeve |
| Mount: | Extended Studs |
| RPM: | 1550 |
| Poles: | 4 |
| Rotation: | CCWLE |
| Enclosure Type: | Totally Enclosed Air Over (TEAO) |
| Speeds: | 1 |
| Phase: | 1 |
| Hertz: | 60 |
| Amperage: | 0.9 |
| Frame: | 42Y |
| Insulation Class: | A |
| Overload Protection: | Automatic |
| Max Ambient Temp (°F): | 104°F |
| Motor Orientation: | Vertical Shaft Up |
