52722439 has been discontinued
Discontinued October 16, 2024
This product was discontinued by the manufacturer.
MANUALS (3)
'/%3E%3C/svg%3E){kind=small}
Product Highlights
–
115V
1/6 HP
Flanged x Flanged Connection
68 MAX GPM
145 MAX PSI
Bronze
Description
–
Note: This circulator requires:
539615: 1-1/2" Bronze Flange Set
539615: 1-1/2" Bronze Flange Set
- 1/6 HP
- 115 Volts
- Pump Connection: GF 40/43 Flange
- Built-in motor protection for long life
- Multiple accessories for a variety of applications
- Whisper-quiet operation for sound sensitive installations
- Applications include Hydronic heating with potable water, Fan coil heating
Specs
–
| Type: | 1-Speed Pump |
|---|---|
| Poles: | 2 |
| Material: | Bronze |
| Frequency: | 60 Hz |
| Mount: | In-Line |
| Amperage: | 2.15 |
| Application: | Heating |
| Voltage: | 115V |
| Max Pressure (PSI): | 145 |
| Horse Power: | 1/6 |
| Max Flow (GPM): | 68 |
| Flow Range (GPM): | 0-68 |
| Head Range (ft.): | 0-13.5 |
| Max Head (Ft): | 13.5 |
| Hertz: | 60 |
| Phase: | 1 |
| Temperature Range (F): | 32°F - 230°F |
| Connection Size: | 1-1/2" |
| Connection Type: | Flanged x Flanged |
