59896121 has been discontinued
Discontinued March 8, 2023
This product was discontinued by the manufacturer.
MANUALS (2)
This item replaces: 59896146
'/%3E%3C/svg%3E){kind=small}
Product Highlights
–
115V
1/25 HP
Sweat Connection
14.7 MAX GPM
145 MAX PSI
Bronze
Description
–
- Built-in motor protection for long life
- Multiple accessories for a variety of applications
- Whisper-quiet operation for sound sensitive installations
- Applications include Hydronic heating with potable water, Fan coil heating
Specs
–
| Type: | 1-Speed Pump |
|---|---|
| Poles: | 2 |
| Material: | Bronze |
| Horse Power: | 1/25 |
| Frequency: | 60 Hz |
| Mount: | In-Line |
| Application: | Heating |
| Voltage: | 115V |
| Amperage: | 0.74 |
| Max Pressure (PSI): | 145 |
| Connection Size: | 3/4" |
| Flow Range (GPM): | 0-14.7 |
| Max Flow (GPM): | 14.7 |
| Max Head (Ft): | 14 |
| Head Range (ft.): | 0-14 |
| Hertz: | 60 |
| Phase: | 1 |
| Temperature Range (F): | 36°F - 230°F |
| Connection Type: | Sweat |
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
You May Also Need
4 Replacement Parts
Replacement Motor Assembly For UP15 Grundfos Pumps
SKU: 506174-GRUNDFOS
GrundfosNeed help finding a replacement part?
Fill out the part request form and someone will get back to you shortly.
PART REQUEST FORM
Product Reviews
5 out of 3 reviews
100% would recommend this product
5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%
Showing 1-3 of 3 reviews
Great Customer Service
I ordered a hot water recirculation pump to replace the original Builder installed pump in my house. The price was reasonable and the customer service was great, i.e., they helped me isolate my problem over the phone and delivered parts quickly. I have not had any issues with the replacement part (been installed for almost two years now). Also, at the time I did need to return one part (not related to any issues of theirs) and was running late on returning the part due to working through a death in my family at the time. They sent me a letter signed by numerous people in their office with their condolences and to tell me not to worry about being late with the return. I was impressed and touched by their letter to me. I will not hesitate to use SupplyHouse for any of my future needs.
Tom K
St. Louis, MO
5 years ago
Verified Buyer
Was this review helpful to you?
Good transaction
Good product worked well for my project fair price
drew
San Diego
11 years ago
Verified Buyer
Was this review helpful to you?
I got just the right part as ordered.
I replaced the same pump that failed after about 10 years. It is used in a 17 plex with 3 75 gallon water heaters.
guy who fixes stuff
Newberg. OR
11 years ago
Verified Buyer
Was this review helpful to you?
Product Q&A
3 Questions3 Questions
Q: does this pump have a thermostat built in?
Asked by cook 10 years ago
Add your answer
Verified Reply- SupplyHouse StaffThis pump line does not have a built in thermostat.
Was this review helpful to you?
Q: does this up15-18b7 pump have a built in thermostat? i was reading some specs on pump and it says it has a timer wasn't for sure if it had a thermostat to turn pump off and on at certain temp.
Asked by cookie 10 years ago
Add your answer
Verified Reply- SupplyHouse StaffThis pump does not have a built in timer. The models with the timer would have the "T" designation in the model number, such as model UP15-18B7/TLC which is sku 59896230. That pump has a built in timer.
Was this review helpful to you?
Q: Is water supposed to be able to flow thru the pump without it being turned on ?
Asked by Richard 10 years ago
Add your answer
Verified Reply- SupplyHouse StaffThere is nothing to stop the flow of water through the pump when it is not powered, so yes water is able to flow through.
