16" X 20" Media Air FilterFC100A1003 16" X 20" Media Air Filter
|1,264||Tue, Jun 7|
Free Shipping On orders over $99
Need replacement parts for this unit?
- Application: Replacement Filter
- Efficiency Standard: Efficiency ratings are based on American Society of Heating, Refrigerating and Air-Conditioning Engineers Standard 52.2-1999.
- Efficiency Standard: Efficiency ranges are defined for small particles, E1=0.3 to 1.0 microns; medium particles, E2=1.0 to 3.0 microns; and large particles, E3=3.0 to 10.0 microns.
- Fractional Efficiency: E1=25%, E2=62%, E3=85%
- Minimum Efficiency Reporting Value (Media Filters Only): MERV 11
- Static Pressure Drop (in. w.c.): 0.23 at 500 FPM
- Nominal Size: 16" x 20" x 4"
- Actual Size: 15-7/8" (15.875") x 19-7/8" (19.875") x 4 3/8" (4.375")
- Efficiency ratings are based on American Society of Heating, Refrigerating and Air-Conditioning Engineers Standard 52.2 1999.
- Efficiency ranges are defined for small particles, E1=0.3 to 1.0 microns; medium particles, E2=1.0 to 3.0 microns; and large particles, E3=3.0 to 10.0 microns.
16" x 20" x 4"
