Dehumidistat, 24/120/240 VAC (White)
 --%3E %3Csvg version='1.1' id='Fill' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23F15C02' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
' fill='%23F15C02' d='M49 0C21.938 0 0 21.938 0 49s21.938 49 49 49 49-21.938 49-49S76.062 0 49 0m0 82.709a7.54 7.54 0 1 1 0-15.08 7.54 7.54 0 0 1 0 15.08m7.54-28.412a7.541 7.541 0 0 1-15.08 0V22.831a7.54 7.54 0 0 1 15.08 0v31.466z'/%3E%3C/svg%3E)
MANUALS (3)
Product Highlights
Description
Features:
- Positive ON-OFF settings permit manual operation of controlled equipment
- Impact-resistant, molded plastic cover mounts on wall
- Fully enclosed, dust free, SPST, snap-acting switch
- Sensing element of thin, moisture sensitive nylon ribbon provides reliable operation even when ambient temperature conditions change
Specs
| Application: | Dehumidification |
|---|---|
| Humidity Range: | 20 to 80% |
| Temperature Range (F): | 50°F to 125°F |
| Voltage: | 240v 24V 120v |
| Mount: | Wall |
| Color: | White |
| Height: | 4-11/16" |
| Width: | 2-15/16" |
| Depth (Inches): | 2-1/8" |
Questions?
Compare Similar Products
24V
120v
You May Also Need
Product Reviews
If I ever needed again.
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Would buy again
works great. simple and easy to use.
good product
Excellent product
Yes
The perfect complement of any thermostat.
Easy remote humidistat solution
Good product.
the good product
Product Q&A
6 QuestionsQ: Will this work with a 240 volt exhaust fan?
Asked by Joe 9 years ago
Add your answer
Verified Reply- SupplyHouse StaffIt could, verify electrical specs of the fan compared to the limits of the dehumidistat.
Q: I can't find my manual that came with my dehumidistat. Having problems of too low temperatures and it seems like the AC comes on every 5minutes
Asked by Mike 11 years ago
Add your answer
Verified Reply- Supplyhouse StaffYou would need to trouble shoot with a technician or honeywell.
Q: I WILL BE LEAVING FLORIDA FOR 9 MONTHS I LIVE IN A MOBILE HOME IN FLORIDA. WHAT SETTING SHOULD I SET IT ON TO LEAVE FOR THAT LONG, THE INSTRUCTIONS SAYS 55. I DON'T WANT MOLD IN HOME WHEN WE COME BACK IN DECEMBER I FILL LIKE 65 OR 70 WOULD BE ENOUGH TO KEEP THE MOLD AWAY THANKS MIKE
Asked by MIKE 11 years ago
Add your answer
Verified Reply- Supplyhouse Staff65/70 is too high...50-55
Q: i have an h46 c 1000, any difference?
Asked by fajitaman 11 years ago
Add your answer
Verified Reply- SupplyHouse StaffThese units are functionally the same. The old H46C1000 was beige while the H46C1166 is white in color.
Q: Is this a reliable humidistat to interface with my home thermostat and air conditioner? Also, why is it called a Dehumidistat and not a Humidistat?
Asked by Dan 14 years ago
Add your answer
Verified Reply- PexSupply StaffA dehumidistat is designed for applications where you are trying to dehumidify, or take humidity out of the air. You would need a humidistat (such as H46E1013) if you are trying to increase humidity.
Dan, This Honeywell De-humidistat is used with your thermostat and air conditioner. It is used to prevent the air conditioning from operating when the humidity level in the house does not exceed the set point of the De-humidistat. The difference between a humidistat and de-humidistat is as follows: First of all they are both switches that open and close based on humidity levels. A de-humidistat switch closes when the humidity level exceeds the set point thus when used with an air conditioner it allows the air conditioner to operate in the home and it not only cools the house but de-humdify's it as well. A Humidistat is used to operate a humidifier on a furnace heating system. This switch works opposite of the de-humidistat. When the set point of a humidistat is achieved the switch opens thus turning off the humidifier. I have this de-humidistat interfaced with my air conditioning unit in Florida. It helps to avoid my running the A/C unit when I am not there and prevents any mold problems from being encountered. The only way my A/C operates is if the humidity level in my home exceeds the set point of the de-humidisat. Generally, Honeywell recommends setting the humidity level at 60%. Hope this helps with your decision to purchase.
A dehumidistat makes contact on a rise in humidity and a humidistat k contact on a fall in space humidity. So the answer depends on if you want to add moisture or reduce it. Best regards, Charlie Pickett DMCA, Inc. ***.****
Q: I wanted to use this product to control a fan in my basement. I was under the impression that the switch would turn on in high humidity and off in low humidity. But after receiving the product and checking with the ohm meter I discovered that it's the opposite, is this true or am I missing something?.
Asked by Andy 14 years ago
Add your answer
I had mine installed to work with the thermostat & whole house AC, when I'm not living in the house located in Florida. In your case I would use the one with the plug & plug adaptor that uses house current to control your fan. I'm not a electric or AC person but I understand the dehumitastat works with low or regular house current. I suggest you get in touch with Honeywell & ask one of there people.
This switch closes when the humidity exceeds the set point. It is open when the humidity level is below the set point. What is the voltage of the fan you are trying to control? Sent from my Verizon Wireless BlackBerry ÂÂÂ
I forgot to ask you the model number of your dehumidistat. You should be using a Honeywell H46C1166 from Pex Supply for 33.59 each to accomplish what you are trying to do. Sent from my Verizon Wireless BlackBerry ÂÂÂ
