Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
2-Way
3/8"
1.6 Cv
35°F Min Temp
3 psi to 10 psi
35°F to 250°F, 35°F to 250°F
Description
–
Normally open, single-seated, high pressure valve provides proportional control of hot and/or cold water in unit air conditioners and fan coil units. Replacement devices are available for Johnson, Powers, Robertshaw, Barber-Colman, and older Honeywell devices.
Features
Features
- Small size permits installation where space is limited.
- Forged brass, straight-through body with end connections threaded for 45 degrees SAE flare fitting nuts.
- Spring-loaded, self-adjusting, Buna-N "V"-ring packing is replaceable without shutting system down.
- High-temperature rolling diaphragm actuator (aluminum cover) and high-temperature plastic diaphragm retaining cup with integral air connection for 1/4 in. (6 mm) O.D. plastic tubing.
- Integral seat and brass plug with removable composition disc provides equal percentage flow.
- Stainless steel stem, 3/16 in. (5 mm) diameter.
Specs
–
| Body Pattern: | 2-Way |
|---|---|
| Type: | Unitary Valve |
| Size: | 3/8" |
| Flow Capacity (Cv): | 1.6 |
| Min Temp (F): | 35°F |
| Spring Range: | 3 psi to 10 psi |
| Temperature Range (F): | 35°F to 250°F 35°F to 250°F |
| Max Temp (F): | 250°F |
