Description
ICM's SimpleComfort PRO thermostats feature innovation and technology that delivers measurable value, simplifies installation and increases profitability. Blending the latest advances in thermostat technology with ICM's new, patented Thermal Intrusion Barrier and patent-pending SimpleSet Target Programming, the PRO series thermostats set new industry standards exclusive to ICM.

The SC5811 programmable thermostat has four periods (MORN, DAY, EVE, NITE) that are customizable for each day of the week. Each period will have a start time, heat temperature, cool temperature and programmable fan option. The SC5811 monitors the day and time, while maintaining the specific conditions you have chosen for each period in your program.

Features
  • For two stage heat/cool or single stage heat pump systems
  • 7-day, 5-2 day and 5-1-1 day programming
  • Compatible with gas, oil and electric systems
  • Anti-short Cycle: 4 minutes (bypass anti-short cycle delay by returning to OFF mode for 5 seconds)
  • ICM patented Thermal Intrusion Barrier
  • ICM SimpleSet Target Programming technology
  • Large display with backlight
  • Permanent memory
  • Programmable fan mode
  • Auto or manual changeover
  • Easy access terminal block
  • Hardwired
  • Field adjustable calibration
  • Adjustable maximum heat/minimum cool setpoints
  • Adjustable temperature differential
  • Configurable remote sensor compatible
  • Keypad lockout
  • Soft touch controls
  • Selectable °F or °C
  • Extra comfort and energy savings modes between stages
  • Status LEDs
Hide Description
Manuals (2)
Specs
Application:

Heat Pump

Multi-Stage (Heat/Cool)

Stages:

2 Heat/2 Cool

Programmability:

5-2 Day

Programmable

7 Day

5-1-1 Day

User Interface:

Push Button

Mount:

Horizontal

Options:

Large Display

Fan Control

Password Lockout

Temperature Control Range:

7°C to 32°C

45°F to 90°F

Voltage:

24v

Amperage:

3 amp max. total load

1 amp max. per terminal

Height:

3.75"

Width:

5.50"

Depth (Inches):

1.12"

Anti-Short Cycle Time (Fixed):

4 minutes

Power Method:

Hardwired

Accuracy:

+/- 1°F

+/- .5°C

×
