PMBD3630 has been discontinued
Discontinued July 16, 2026
This product was discontinued by the manufacturer.
MANUALS (1)
Suggested Alternative:
3-Port Branch Distribution Box for Multi F MAX & Multi F MAX w/ LGRED Outdoor Units
VIEW ALTERNATIVE --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Product Highlights
–
208/230V
0.1 Amps
Description
–
Note: This item is for R-410A units only, and is not compatible with R-32 or R-454B units.
Features:
- Distributes refrigerant to indoor units
- Internal components are insulated
- Flare joints provided for easy installation
- Compact design
Piping
- Piping Connection to Outdoor Unit
- Liquid Line (OD) : 3/8"
- Vapor Line (OD) : 3/4"
- Piping Connection to Indoor Unit
- Liquid Line (OD) : 1/4" (Qty 3)
- Vapor Line (OD) : 3/8" (Qty 3)
Performance:
- Max Port Capacity Btu/h (each port) : 24,000
- Max Unit Capacity Btu/h (sum of ports) : 72,000
- Power Input (W): 10
Specs
–
| Product Type: | Distribution Unit |
|---|---|
| Voltage: | 208/230V |
| Hertz: | 60 |
| Phase: | 1 |
| Amperage: | 0.1 |
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
You May Also Need
Product Reviews
5 out of 2 reviews
100% would recommend this product
5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%
Customer Images
Showing 1-2 of 2 reviews
LG Mini Split Zone Distribution Box
Worked perfectly. But please be aware, this is for LG multizone systems only.
HVAC Papa
Camdenton, MO.
3 years ago
Verified Buyer
Was this review helpful to you?
Great distribution box
Bought 2 of them for 5 zone system. Easy installation, easy wiring. System works great. When it works makes slight whistling noise from refrigerant movement.
Mitch
Sacramento,CA
5 years ago
Was this review helpful to you?
Product Q&A
1 Question1 Question
Q: what comes with the distribution unit
Asked by phil 11 years ago
Add your answer
Verified Reply- Supplyhouse Staffthey only come with the flair nuts to attach the piping.
Was this review helpful to you?
