Note: The vent protector (13A15) is not included and can be purchased separately
This product should be installed by a licensed gas fitter.
All models except RV131 are CSA design certified for 1/2 psi rated pressure under the ANSI standard for gas pressure regulators; and CSA listed to certify compliance with nationally published safety, construction, and performance standards. Models are certified for 1/2 PSI Max Inlet Pressure (CSA Certified) and are 1 PSI Max Inlet Pressure (Maxitrol Tested).
They are main burner only, non-lockup type. They should not be used as a line gas pressure regulator ahead of low pressure controls. Use only where downstream controls can operate at line pressure.
The RV52, RV53, & RV61 are suitable for multipoise mounting. The RV81, RV91, RV111, & RV131 are recommended for normal horizontal position only.
