3/4" Sediment Removal Water Filter (Plastic)
Hover image to zoom

3/4" Sediment Removal Water Filter (Plastic)

SKU:
F76S1015
Rating:
(35)
Q&A:
(16)
3/4" Sediment Removal Water Filter (Plastic)
Hover image to zoom
$362.71 each
In Stock
In Stock
Get 9 Wed, Mar 6
More Available
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days

Product Highlights

Size icon
3/4"
Material icon
Plastic Sump
Connection Type icon
Sweat, NPT Connection
Height icon
17-11/16"
Diameter (Inches) icon
3-13/16" Diameter
Max Pressure (PSI) icon
230 PSI

Description

**Shown with Plastic Sump

Specifications
  • Description - 3/4 inch Water filter
  • Pipe Size (inch)- 3/4 in.
  • Pipe Size (DN)- DN15
  • Connection Type - NPT External Threaded and Sweat
  • Sump - Clear Plastic
  • Capacity (Cv) - 11 Cv
  • Capacity (Kv) - 9.4 Kv
  • Pressure Ratings (psi) - 230 psi maximum
  • Dimensions (in.) - 17 11/16 in. high x 7 in. wide x 3 13/16 in. deep
  • Dimensions (mm) - 449 mm high x 178 mm wide x 97 mm deep
  • Weight (lb) - 6.4 lb
  • Weight (g) - 2.9 kg
  • Screen Size - 100 micron screen
  • Temperature Rating (F) - 104 F Maximum
  • Materials (Body) - Brass
  • Temperature Rating (C) - 40 C Maximum
  • Includes - gauge and service wrench

Features
  • Whole House Protection
  • Ideally suited for sediment removal applications that would quickly plug and restrict the flow of normal filters.
  • Used as a prefilter, the F76 protects elements of the water system, including specialized treatment devices or other common fixtures and appliances.
  • The flow filtering capacity and ease of cleaning make the F76S ideal for the most demanding applications.
  • Built-in secondary filter provides an uninterrupted supply of filtered water during backwashing.

Specs

Product Type:

Filtration System

Application:

Point of Entry

Pre-Filter

Commercial

Plumbing

Type:

Whole House

Sediment

Flow Rate (GPM):

3.2

Micron Rating:

100

Max Water Temp (°F):

104°F

Size:

3/4"

Material:

Plastic Sump

Connection Type:

Sweat

NPT

Height:

17-11/16"

Diameter (Inches):

3-13/16"

Reduction Claim:

Sediment

Rust

Max Pressure (PSI):

230

Thread Type:

Male

Temperature Range (F):

104°F Max
