$229.93 each
In Stock
Get 24 Tue, Jun 23
Order by today, receive Tuesday
MANUALS (1)
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
.5 PSI
9 MAX PSI
Description
–
Specifications:
Application: Safety control for steam heating boilers
Pressure Ratings (Set Point): Recommended minimum set point is differential setting plus 1 1/2 psi.
Pressure Sensing Element: Stainless Steel diaphragm
Switching Action: Makes at set point on pressure fall; Breaks at set point plus differential on pressure rise
Switch Type: SPST snap-acting switch
Pipe Connections: 1/4 in. female pipe threads
Pressure Surge (max. psi): 50 psi
Pressure Surge (max. kPa): 345 kPa
Adjustable Scale Range (psi): 0.5 psi to 9 psi
Adjustable Scale Range (kPa): 3 kPA to 62 kPa
Adjustable Operating Pressure Range (psi): 0.5 psi to 9.0 psi
Adjustable Operating Pressure Range (kPa): 3 kPa to 62 kPa
Maximum Operating Pressure (psi): 20 psi
Maximum Operating Pressure (kPa): 137 kPa
Differential Pressure Range (psi): Additive: 1 psi to 5 psi
Differential Pressure Range (kPa): Additive: 7 kPa to 35 kPa
Electrical Ratings: 0.25 A @ 0.25 to 12 Vdc
Electrical Ratings (120 Vac, Full Load): 8.0 A
Electrical Ratings (120 Vac, Locked Rotor): 48.0 A
Electrical Ratings (120 Vac, Resistive): 8.3 A
Electrical Ratings (240 Vac, Full Load): 5.1 A
Electrical Ratings (240 Vac, Locked Rotor): 30.6 A
Electrical Ratings (240 Vac, Resistive): 8.3 A
Electrical Ratings (277 Vac, Resistive): 7.2 A
Electrical Ratings (Pilot Duty): 150 VA @ 277 Vac
Materials (Case): Gray enamel finish
Maximum Ambient Temperature (F): 150 F
Maximum Ambient Temperature (C): 66 C
Operating Humidity Range (% RH): 95% RH, non-condensing
Dimensions (in.): 4 15/32 in. high x 3 3/8 in. wide x 2 1/4 in. deep
Dimensions (mm): 114 mm high x 86 mm wide x 58 mm deep
Approvals, Underwriters Laboratories Inc UL Listed: File no. MP466, Guide no. MBPR.
Approvals, Canadian Standards Association CSA Listed: File no. LR1620.
Tradeline Value: Tradeline
Ref: Honeywell.com
Application: Safety control for steam heating boilers
Pressure Ratings (Set Point): Recommended minimum set point is differential setting plus 1 1/2 psi.
Pressure Sensing Element: Stainless Steel diaphragm
Switching Action: Makes at set point on pressure fall; Breaks at set point plus differential on pressure rise
Switch Type: SPST snap-acting switch
Pipe Connections: 1/4 in. female pipe threads
Pressure Surge (max. psi): 50 psi
Pressure Surge (max. kPa): 345 kPa
Adjustable Scale Range (psi): 0.5 psi to 9 psi
Adjustable Scale Range (kPa): 3 kPA to 62 kPa
Adjustable Operating Pressure Range (psi): 0.5 psi to 9.0 psi
Adjustable Operating Pressure Range (kPa): 3 kPa to 62 kPa
Maximum Operating Pressure (psi): 20 psi
Maximum Operating Pressure (kPa): 137 kPa
Differential Pressure Range (psi): Additive: 1 psi to 5 psi
Differential Pressure Range (kPa): Additive: 7 kPa to 35 kPa
Electrical Ratings: 0.25 A @ 0.25 to 12 Vdc
Electrical Ratings (120 Vac, Full Load): 8.0 A
Electrical Ratings (120 Vac, Locked Rotor): 48.0 A
Electrical Ratings (120 Vac, Resistive): 8.3 A
Electrical Ratings (240 Vac, Full Load): 5.1 A
Electrical Ratings (240 Vac, Locked Rotor): 30.6 A
Electrical Ratings (240 Vac, Resistive): 8.3 A
Electrical Ratings (277 Vac, Resistive): 7.2 A
Electrical Ratings (Pilot Duty): 150 VA @ 277 Vac
Materials (Case): Gray enamel finish
Maximum Ambient Temperature (F): 150 F
Maximum Ambient Temperature (C): 66 C
Operating Humidity Range (% RH): 95% RH, non-condensing
Dimensions (in.): 4 15/32 in. high x 3 3/8 in. wide x 2 1/4 in. deep
Dimensions (mm): 114 mm high x 86 mm wide x 58 mm deep
Approvals, Underwriters Laboratories Inc UL Listed: File no. MP466, Guide no. MBPR.
Approvals, Canadian Standards Association CSA Listed: File no. LR1620.
Tradeline Value: Tradeline
Ref: Honeywell.com
Specs
–
| Pressure Range: | .5 psi to 9.0 psi |
|---|---|
| Min Pressure (PSI): | .5 |
| Max Pressure (PSI): | 9 |
| Min Pressure Differential (PSI): | 1 |
| Max Pressure Differential (PSI): | 5 |
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
You May Also Need
Product Reviews
4.54 out of 13 reviews
92% would recommend this product
5 star
85%
4 star
0%
3 star
8%
2 star
0%
1 star
8%
Most Liked Positive Review
Just want I needed
This product fit perfectly, didn't need to anything but tighten some screws and use wrench to tighten onto pipe. Works great!
VS
Most Liked Negative Review
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Device not claibrated
I bought this to replace an existing controller that did not work well. Unfortunately the new device did not work at all - my boiler would not shut off based on pressure.I took the device in to my office to check the calibration on a Fluke calibrator - the "cut-in differential" worked great, but the "cut-out" did not work at all - either the spring was not calibrated or the diaphragm was damaged. Unfortunately for low pressure single pipe steam boiler owners like me - there is no good product on the market that I could find that has a low control range. Ideally a controller with a 0-2 psi range with a time delay between starts would be best - I would like my cut-out pressure to be 0.5 psi with a 15 minute delay between starts.
Showing 1-10 of 13 reviews
Product Great; Delivery Terrible
Product is as expected.
Website promised next day delivery. Actual delivery time was 3 days. Had I known the true delivery time I would have purchased the part elsewhere.
Boiler Guy
Indy
2 years ago
Verified Buyer
Was this review helpful to you?
it works
easy install and working great
G
Denver CO
3 years ago
Verified Buyer
Was this review helpful to you?
Yes
Excellent service and product
Shotgun
Rochester ny
4 years ago
Verified Buyer
Was this review helpful to you?
Same as Honeywell
Replaced the original Honeywell with this, and it simply worked.
Wei
New Jersey
5 years ago
Verified Buyer
Was this review helpful to you?
Works as promised
Works as promised
QUADZILLA
NY
5 years ago
Verified Buyer
Was this review helpful to you?
Just want I needed
This product fit perfectly, didn't need to anything but tighten some screws and use wrench to tighten onto pipe. Works great!
Harry
Bloomfield, NJ
6 years ago
Verified Buyer
Was this review helpful to you?
Works Great
Direct replacement for my steam boiler. Works perfectly.
Todd
NJ
6 years ago
Verified Buyer
Was this review helpful to you?
Just what I needed.
Great product, just as described. Service is quick and efficient.
Mark
Brooklyn, NY
7 years ago
Verified Buyer
Was this review helpful to you?
Exactly what I needed
Exact Replacement. Works as intended
Cye's HVAC
New York
7 years ago
Verified Buyer
Was this review helpful to you?
Pressuretrol
Direct replacement for boiler pressure switch. Easy installation. Works like a charm.
Chris
Waterford, CT
10 years ago
Verified Buyer
Was this review helpful to you?
Product Q&A
6 Questions6 Questions
Q: What is the warranty on this item?
Asked by Rex 8 years ago
Add your answer
Verified Reply- Hello Rex, The Warranty on this would be one year.
Was this review helpful to you?
Q: I have a unit marked "PA404A. 1009". Can this unit be used as a replacements? Thank you.
Asked by Rog 11 years ago
Add your answer
Verified Reply- Supplyhouse Staffthe correct replacement is 400-117-000.
Was this review helpful to you?
Q: Does a siphon come with the product ?
Asked by d 11 years ago
Add your answer
Verified Reply- SupplyHouse StaffNo,this unit does not include a siphon, however one is recommended by Honeywell for installation on the system.
Was this review helpful to you?
Q: what exactly is this unit for . can you describe its function please? thank you
Asked by deke 12 years ago
Add your answer
Verified Reply- PexSupplyStaffA pressuretrol is a control used to control a steam boiler, by setting when the boiler should begin/ end firing based on steam pressure. The pressuretrol is generally secondary to a thermostat.
Was this review helpful to you?
Q: how offten dose this part need to be replaced
Asked by 15 years ago
Add your answer
Verified Reply- PexSupply StaffIt should not need to be replaced very often. We would estimate every 12-20 years.
Was this review helpful to you?
- jkszip
Not usual, but if it does not sense H/W, and you give it a rap and it cuts in... then replace it. Hard H/W failure..replace it and use PexSupply. Easy install... if your not an accountant!
Was this review helpful to you?
Q: what is the recommended setting
Asked by learning 16 years ago
Add your answer
Verified Reply- PexSupply StaffPA4041033 comes with a range of .5 to 9 PSI, it is factory set at 8, range can be set anywhere between .5 and 9. It is up to the technician to determine the optimal setting.
Was this review helpful to you?
