Description
Overview:
Combination gas control for use in 24 Vac, gas-fired, intermittent pilot appliances with capacities from 30 to 415 cfh.

Features:
  • Controls include safety shutoff, manual valve, two automatic operators, pressure regulator and pilot adjustment.
  • Use with S86F,H; S860D; S8600F,H; S8610 and S90A,B Control Modules.
  • Compact size.
  • Provide two automatic valves. Solenoid operated first automatic valve opens on thermostat call for heat; closes when call for heat ends.
  • Diaphragm-operated second automatic valve opens under control of regulator; closes if gas or power supply is interrupted.
  • Meet codes requiring dual safety shutoff.
  • Natural to LP and LP to Natural conversion kits available for standard and slow opening gas valves.
  • All adjustments, wiring connections and pilot outlet are accessible from top of control.
  • Adjustable servo regulator effectively maintains almost constant gas output pressure under wide fluctuations in gas supply pressure.
  • Compatible with ECO connector.
  • ON-OFF lighting sequence.
  • Read more
    Specs
    Type:
    Single Stage
    Ignition Type:
    Intermittent Pilot
    Fuel Type:
    Propane
    Gas Type:
    Liquid Propane
    Body Pattern:
    Straight-Through
    Capacity (BTU):
    300000
    Pressure Rating:
    1/2 psi
    Min Temp (F):
    -40°F
    Max Temp (F):
    175°F
    Temperature Range (F):
    -40°F to 175°F
    Inlet Size:
    3/4"
    Outlet Size:
    3/4"
    ×
