1/2" MLC Fitting Assembly, R20 thread
Hover image to zoom

1/2" MLC Fitting Assembly, R20 thread

SKU:
D4120500
Rating:
(2)
Q&A:
(2)
1/2" MLC Fitting Assembly, R20 thread
Hover image to zoom
D4120500 has been discontinued
Discontinued October 13, 2018
This product was discontinued by the manufacturer.

Product Highlights

Material icon
Brass
Tubing Compatibility icon
PEX-AL-PEX
Fitting System Compatibility icon
PEX-AL-PEX Compression
Standards Met icon
NSF, ASTM F877 Standards Met
Connection Size icon
R20 x 1/2" Connection
Max Pressure (PSI) icon
200 PSI

Description

MLC Compression Fitting Assemblies, made of heat-treated brass, connect 1/2" PEX-AL-PEX tubing to 1 1/4" Brass and TruFLOW manifolds (R20 thread). They can also be used to make other connections using R20 adapters. Note: The 3/4" MLC Fitting Assembly has R25 threads and will not thread directly onto 1 1/4" Brass and TruFLOW manifolds.

Specs

Connection Size:

R20 x 1/2"

Material:

Brass

PEX Size:

1/2"

Application:

Accessory

Max Pressure (PSI):

200

Warranty:

5 Year

Standards Met:

NSF

ASTM F877

Tubing Compatibility:

PEX-AL-PEX

Fitting System Compatibility:

PEX-AL-PEX Compression

Max Temp (F):

200°F

Thread Size:

R20
