Lift Gate
Product Highlights
Description
What makes the Alliance SL unique is the Hydrastone-lining. This one half inch lining protects the steel tank from the corrosive action of water. When the water first enters the tank, it is absorbed into the Hydrastone-lining permanently. This water loses its oxygen and becomes inert, non-corrosive water which then acts as a protective wall between the hot water and steel tank. This unique process and design makes Alliance SL water heaters a great choice for domestic hot water applications.
- Maximum First Hour Rating at 135°F (gal./hr.) : 225
- Continuous Draw Rating at 135°F (gal./hr.) : 171
- Standby Loss (°F/hr.) : .56
- Minimum Boiler Output (MBtu/hr.) : 110
- Boiler Water Flow Rate (gal./min.) : 6
- Pressure Drop through Coil (ft. w.c.) : 9.5
- Storage Capacity (gal.) : 50
- Height (in.) : 40-3/4
- Diameter (in) : 26
- Maximum Allowable Working Pressure : 150 psi
- Approximate Shipping Weight (lbs.) : 248
- A 10-year full tank replacement, two-year labor and one year on parts, which include the coil, come with every Alliance SL.
- Hydrastone-lining
Specs
| Capacity (Gallons): | 50 |
|---|---|
| BTU Input: | 110000 |
| Height (Inches): | 40.75" |
| Application: | Plumbing |
| Diameter (Inches): | 26" |
| Water Connection: | 3/4" |
| Size: | 3/4" |
| Circulator (GPM): | 6 |
| Continuous Draw: | 171 Gallons/Hr @135F |
| 1st Hour Delivery (Gallons): | 225 Gallons @ 135°F |
| Warranty: | 10 Year Limited (Tank), 1 Year Limited (Parts) |
| Max PSI (Boiler): | 45 psi |
| Max PSI (Domestic): | 150 psi |
Questions?
You May Also Need
6 Replacement Parts
Need help finding a replacement part?
Product Reviews
Most Liked Positive Review
Low profile and very heavy duty
Most Liked Negative Review
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Plenty of hot water - Smelly hard water
i would buy again
Yes
I dont know if I would buy it again, it's too early to say,
Quality product
High quality!
Exactly as ordered adn delivered quick!
Works well but beware of the fine grit
Would buy again
Excellent product
Yes
Product Q&A
10 QuestionsQ: I assume I will need a circulator. Would you recommend the TACO 007 or the 0010? The TACO 0010 seems to be a closer match given the 9.5 head. Thanks
Asked by GR 11 years ago
Add your answer
Verified Reply- Supplyhouse Staffwe are not able to size circulators, you can use the guide linked below. http://s3.supplyhouse.com/manuals/1289252668477/41390_PROD_FILE.pdf
Q: Do I need to purchase a seperate aquastat for indirect water heater?
Asked by Matthew 12 years ago
Add your answer
Verified Reply- SupplyHouse StaffNo, this indirect water heater includes an aquastat (TPI control). For information on setting the controls please see pg 9-11 here: http://s3.supplyhouse.com/product_files/AL50SL-Install.pdf
Q: What is the units efficiency rating percentage?
Asked by topnote 12 years ago
Add your answer
Verified Reply- PexSupplyStaffThe Unit has an 87% energy efficiency rating.
Q: Family of 4, 2 adults, 2 young daughters. next couple of years we will all be showering in the morning (2 bathrooms). will the 50 work or do i really need the 70?
Asked by michael from boston 13 years ago
Add your answer
If you have standard showers with a single shower head and a boiler with a domestic hot water priority control, even a 30 gallon indirect water heater would be adequate. I have two showers, but one is configured as a vertical spa with a large shower head and four body sprays for which an auxiliary pump is used to increase the water pressure to drive the five heads. I bought the 50 gallon water heater based on the better flow rate specifications and have never run out of hot water using both showers. A 50 gallon heater would be a better choice if your boiler does not have a domestic hot water priority control. In either case, a 70 gallon would be way-overkill. With a 70 gallon tank, you would also be heating up a larger volume of water unnecessarily. Domestic hot water priority control is the ability of the boiler to provide full attention to producing hot domestic water when demanded; while suspending heating of the hot water for home heat as long as there is a demand for domestic hot water (during the relatively short period that people would be taking a shower). When there is no longer a demand for domestic hot water, the boiler will return to heating hot water for home heat.
Yes. Fast recovery if water heated by a boiler. We have had 12 people using 4 showers never a problem. But we also heat with a boiler. Jim Sent from Jim Weaver's iPad3
You should be fine we have three adults and one children. The tank is plenty big.
We are a family of 6. We have never had an issue with running out of hot water. I would say the 50 is the way to go. Sent from my iPhone
Yes. We have 2 adults, and 4 kids (two teenagers and two little ones) and it keeps up. We sometimes have 2 showers at the same time or a shower and and a wash load along with the heaters in the winter and it keeps up just fine. The only time I’ve had to wait for hot water is when the furnace has turned off for some reason! (It was bigger than we thought, if you have a confined space to put it in it would be a good idea to check dimensions.)
Q: I am thinking of installing this unit to replace a traditional 50 gal water heater. After reading the other questions and answers, and reviews, I am wondering if I need a new 50 gal unit or if a smaller one will work fine. I live in a small town home, only 1 bath. There are only 3 of us, but if I sell someday, there of course could be more people living here.
Asked by Stefanie 14 years ago
Add your answer
I have the 50 and even with 12 house guests and 4 full baths it has never run out of hot water. Your boiler roaches the water with 180 degree water. Conclusion, I would think a smaller tank would be more then sufficient. Jim Sent from Jim Weaver's iPad
I have this very same unit and it is great. There are 3 of us and I have an outdoor furnace which heats this unit. This is probably the best solution to hot water heating I've ever seen. We never need to worry about lack of hot water. I personally would not go to a smaller unit unless space is an issue. This unit should not cost any extra to operate than a smaller one since it holds heat very well.
I'd go with the 50. We are three here as well and it is perfect. Scott Feero
Yah I think the smaller one would be fine but I can’t say for sure since I have a 50 gallon. We have 3 baths and 6 people and an endless hot water supply. Someone with the smaller size would be a better resource.
The smaller unit should be fine for your 1 bathroom townhome. Make sure your boiler is capable of providing enough output and water tank is on Priority Zone. Also note the weight of the unit. Very heavy.
We have a family of 4 that love long showers and ha Garret Sent from my iPhone
Never ran out of water. We love to unit. I would recommend it. Garret Sent from my iPhone
Q: I have a Burnham ES2-4. Will I be able to install an indirect water heater on this unit?
Asked by scoester 14 years ago
Add your answer
Verified Reply- PexSupply StaffYes, you can connect an indirect water heater to an ES2 boiler.
Yes. You'll need to have an additional zone added to your heating system dedicated to circulating boiler water through the heat exchanger in the indirect water heater.
Yes, it is just another loop off the boiler.
My indirect hot water heater is to the furnace a second heating zone, so the controller on your furnace must allow two zones. I am not a plumber, but I'm pretty sure your can replace the controller if necessary.
Yes, you can add an indirect water heater to this unit. You will need to add a zone for the water heater and if you use the burnham hydrostone lined indirect water heater you'll want to have that zoned with a pump as the pressure drop across the coil is significant. If your heating system is currently zoned with zone valves it will be a decent project to reconfigure for the additional zone. You'll also want priority for the indirect water heater. John White Process Engineer
i use a pvg4 boiler with 3 different indirect water heaters 1 for my potable water 1 for my breezeway heat and al50sl indirect water heater just for my house infloor heat runs. i would recemend indirect heaters for boiler systems . i found that just useing a boiler with a mixing valve into the floor runs are not as good as useing a idirect water heater to do the 2000feet of pex runs . i have a 2800 squ foot house and with an 80 dollar gas bill for heat and also potable hot water. im very happy with my puchase
Q: I currently have a Top Performer S50TPP it is leaking at the base. I thinking of replacing it out with this AL50SL. Will this be ok?
Asked by 14 years ago
Add your answer
Verified Reply- PexSupply StaffThat should be fine, as long as the existing unit is 50 gallons. Indirect water heaters tend to be interchangeable and they work with any type of boiler.
Q: i'm looking to install this to my burnham gas boiler. i have an exsiting 40 gas chimney water heater. i have a 3 story victorian house, 3 baths and a family of 5. 3 floors of wonderful radiant heat from cast iron radiators. will this sl 50 work for my application and will i need to add a circulating pump on the water heater side of the piping. thanks
Asked by stp 15 years ago
Add your answer
Verified Reply- PexSupply StaffThis unit will work. You will need a circulator pump for the indirect water heater.
Q: Is this oil fired? And will it work with a Weil Mclain Boiler?
Asked by 15 years ago
Add your answer
Verified Reply- PexSupply StaffAll indirect water heaters are powered by the boiler that is connected to them. They generally work with any boiler.
Q: I just had the 50 gallon indirect installed on Friday. The hot water has a slight odor. I am assuming that this condition will disappear after a while, but should I be concerned? Sometimes the water will have an ammonia smell.
Asked by Edward 15 years ago
Add your answer
Verified Reply- PexSupply StaffWe recommend flushing the system to make sure there is no solder in the piping or other items.
