$203.73 each
In Stock
Get 3 Tue, Jul 7
Order by today, receive Tuesday
MANUALS (4)
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
208V, 230V, 208/230V
1075 RPM
Reversible
1/10 HP
Extended Studs
0.7 Amps
Description
–
Features:
- Stud or Belly Band Mount
- Frame - 48
- Overload - Automatic
- Length less shaft - 3.75"
- Energy Efficient
- All Angle Mount
- Permanent Split Capacitor
- 60° or 70° C Ambient
- Class B or Class F Insulation
- Auto Protector
- Ball or Sleeve Bearing
- Reversible
- 1/2" Dia. Flatted Shaft
- 6 and 8 Pole
- 26" (Minimum) to 48" Leads
- Extended Thru Bolts
- 60 HZ
Specs
–
| Type: | Permanent Split Capacitor |
|---|---|
| Horse Power: | 1/10 |
| Voltage: | 208V 230V 208/230V |
| Enclosure Type: | Totally Enclosed |
| Duty: | Air Over |
| Rotation: | Reversible |
| Poles: | 6 |
| Mount: | Extended Studs |
| Bearings: | Sleeve |
| Phase: | 1 |
| RPM: | 1075 |
| Hertz: | 60 |
| Frame: | 48Y |
| Insulation Class: | B |
| Speeds: | 1 |
| Amperage: | 0.7 |
| Overload Protection: | Automatic |
| Diameter (Inches): | 5-5/8" |
| Shaft Length: | 6" |
| Max Ambient Temp (°F): | 140°F |
| Motor Orientation: | Any |
