978 has been discontinued
Discontinued October 17, 2024
This product was discontinued by the manufacturer.
MANUALS (1)
Product Highlights
–
115V
1050 RPM
CWSE
1/20 HP
Extended Studs
1.7 Amps
Description
–
Features:
- Continuous Duty, Air Over
- 60 Hz
- Auto Protector
- Sleeve Bearing
- 40 Degrees C Ambient
- Motor Diameter: 5"
- Motor Length (less shaft): 4 1/4"
- Shaft Dimensions: 3/8 x 3" flatted
- 1/20 HP
- 1050 RPM
- 115 Volt
- 1.7 Amps
- Capacitor Shaded Pole
- Rotation: CWSE (clockwise shaft end)
- 1 Speed
- OEM Replacement for 7151-2951, Fasco D242
Specs
–
| Type: | Permanent Split Capacitor |
|---|---|
| Horse Power: | 1/20 |
| Bearings: | Sleeve |
| Voltage: | 115V |
| RPM: | 1050 |
| Phase: | 1 |
| Enclosure Type: | Totally Enclosed |
| Frame: | 42 |
| Rotation: | CWSE |
| Mount: | Extended Studs |
| Hertz: | 60 |
| Speeds: | 1 |
| Amperage: | 1.7 |
| Overload Protection: | Automatic |
| Diameter (Inches): | 5" |
| Insulation Class: | B |
