$205.67 each
In Stock
Get 25 Tue, Jun 16
Order by today, receive Tuesday
MANUALS (3)
This item replaces: 59896173, 59896274
'/%3E%3C/svg%3E){kind=small}
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
230V
1/25 HP
Flanged x Flanged Connection
17.5 MAX GPM
145 MAX PSI
Cast Iron
Description
–
Grundfos Series UP circulators are engineered
to meet the demands of residential hot water
and heating systems applications. The UPS 15-42 F works in a variety of closed loops applications
variety of open and closed loop applications.
Features:
Features:
- UPS Closed System 3-Speed Circulator Pump
- Automatic resetting thermal protection
- Multiple accessories for a variety of applications
- Whisper-quiet operation for sound sensitive installations
- Pump Connection: GF 15/26 Flange
Specs
–
| Frequency: | 60 Hz 60 Hz 60 Hz |
|---|---|
| Poles: | 2 |
| Material: | Cast Iron |
| Voltage: | 230V |
| Hertz: | 60 |
| Phase: | 1 |
| Horse Power: | 1/25 |
| Amperage: | 0.41 |
| Wattage: | 92 |
| Max Pressure (PSI): | 145 |
| Type: | 3-Speed Pump |
| Flow Range (GPM): | 0-17.5 |
| Max Flow (GPM): | 17.5 |
| Head Range (ft.): | 0-15.5 |
| Max Head (Ft): | 15.5 |
| RPM: | 2450 |
| Temperature Range (F): | 36°F - 230°F |
| Connection Size: | 1-1/2" 1" 3/4" 1-1/4" |
| Connection Type: | Flanged x Flanged |
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
You May Also Need
3 Replacement Parts
Need help finding a replacement part?
Fill out the part request form and someone will get back to you shortly.
PART REQUEST FORM
Product Reviews
4.89 out of 9 reviews
100% would recommend this product
5 star
89%
4 star
11%
3 star
0%
2 star
0%
1 star
0%
Showing 1-9 of 9 reviews
Good product
Pump works Great, fast lead time, priced well. in stock
Ray
Souderton, PA
5 months ago
Verified Buyer
Was this review helpful to you?
Good product
Good service.
LQ
Miami
4 years ago
Verified Buyer
Was this review helpful to you?
IT WAS THE REPLACEMENT PRODUCT
THEY HELPED ME BY MAKING SURE IT WAS THE REPLACEMENT PRODUCT, AND ANSWERED BY QUESTIONS ABOUT IT.
JOSEPH
NEW JERSEY
5 years ago
Verified Buyer
Was this review helpful to you?
Yes buy agian
Great item fast service
BigKen
Fresno
7 years ago
Verified Buyer
Was this review helpful to you?
works well
used on the boiler side of a spa heat exchanger, fore some reason (LOL), after 22 years it needed to be replaced !!
Thad
ID
7 years ago
Verified Buyer
Was this review helpful to you?
I would purchase this product in the future
we use this part in our wax injection machine for sending water through the heaters.
ddullum
chandler, arizona
7 years ago
Verified Buyer
Was this review helpful to you?
Yes
Work like I need it to
Jim
Eagar az
8 years ago
Verified Buyer
Was this review helpful to you?
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Worked in my 125 vold circuit....
Bought this as an exact replacement for the 230 volt pump that failed after 15 years in service in my home. Installed the new pump and it worked fine. Found that the original pump failed with a fire under the electical cover - so decided to replace the new pump with a 125 volt unit the same as another zone pump in the system. Keeping the 230 volt pump as a backup to use when the next failure occurs. Overnight delivery of the 230V pump worked as advertised but was too ecpensive.
Mike T
Near Boston
11 years ago
Verified Buyer
Was this review helpful to you?
Whisper quiet on all three speeds
Used on my garage infloor heating system.
GAV
Medford, MN
15 years ago
Verified Buyer
Was this review helpful to you?
Product Q&A
4 Questions4 Questions
Q: I have to replace my recirculating pump and not sure which one to get. The one I have now is TYPE UPS 15-42 SF, please let me know what to get. Thanks, Sandy
Asked by saz 10 years ago
Add your answer
Verified Reply- SupplyHouse StaffThe replacement pump looks like it would be the UPS15-35SFC which is sku 59896772.
Was this review helpful to you?
Q: I have this model on my hot water heating system and it is wired for 110 volt. Can this model UPS 1542F be wired for 110 volt as well as 230 volt? Or is there another model for my system?
Asked by Bob 12 years ago
Add your answer
Verified Reply- SupplyHouse StaffYou could likely wire the pump for 110 volts using proper transformers and electrical equipment. You could consider a UP15-42F (part 59896155). This 115-volt's lone speed falls between Speed 1 and Speed 2 of the UPS15-42F. The UPS15-58FC (part 59896341) is a 115-volt, 3-speed pump that is very similar to the UPS15-42F.
Was this review helpful to you?
Q: I am trying to replace UP 15-42SF on my home hot water heater circulation. This pump looks like it would work, but I need stainless steel rather cast iron. Any help?
Asked by Angie 14 years ago
Add your answer
Verified Reply- PexSupply StaffThe one that you need is part 59896772 (UPS15-35SFC Stainless Steel 3-Speed Flanged Circulator Pump, 3/20 HP, 115 V)
Was this review helpful to you?
Q: I have to replace my circulation pump the volt is 115 can i use a pump with a 230 volt. Will it make a difference.
Asked by 14 years ago
Add your answer
Verified Reply- PexSupply StaffYou can use a 230 volt pump, but it would likely be much more difficult to supply it with power.
Was this review helpful to you?
