Material: | Cast Iron |
---|---|
Application: | Heating |
Type: | Pump Flanges |
Thread Type: | Female |
Connection Size: | 1-1/4" |
Thread Size: | 1-1/4" |
Connection Type: | Threaded |
Used With: | 00 Series Pumps 110 Pumps 111 Pumps 112 Pumps 113 Pumps 1400-10 Pumps 2400-10 Pumps 2400-20 Pumps 1400-45 Pumps |
I would not think so, the extra cost because there is more than on seal to protect water from getting into the motor. This will prevent the water from electrical current flow.
I don't use dielectric unions when connecting to copper and have never had a problem with the flange, pump or copper.
No, but a better way is to use a Webstone flange as it is brass and will work with any 2 bolt pump flange.
If i was using copper, would put the union in, will save a lot of work later.
yes
It will if the __inside diameter of the pipe is 1 1/4 inches.
In most cases that is all that is needed.
Yes.
Yes the O ring should be in the bag that is all you need. It is hard to believe that it will hold water but those flanges work very well. Just get the O ring seeting in the groove line it up and tighten it down.
Yes I also recommend putting ball valves in the line on either side of the flanges to facilitate easy and swap out of the pump in the future without draining the whole system down
Yes, use pipe tape for the threaded fitting.
