MANUALS (1)
Product Highlights
Description
Specs
| Size: | 1" |
|---|---|
| Connection Type: | MNPT |
| Lead Free: | Yes |
| Material: | Brass |
| Application: | Plumbing |
| Max Pressure (PSI): | 200 |
| Warranty: | 5 Year |
| Thread Type: | Male |
| Standards Met: | ASTM F877 NSF ASTM F1960 |
| Tubing Compatibility: | PEX |
| Manifold Compatibility: | Manabloc |
| Max Temp (F): | 200°F |
Contact
Happy Independence Day!
You May Also Need
Product Reviews
Most Liked Positive Review
Excellent Product
Most Liked Negative Review
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Would appreciate a hex fitting
Works as expected
Perfect fit for my Manabloc
Excellent products and services, fast delivery times also
Adapters
Most definitely
Would appreciate a hex fitting
OneHappyPlumbBob
worked
Very Well Made!
Perfect fit
Product Q&A
13 QuestionsQ: I purchased the manablock 36144 and I need to know what is the best supply adapter for the main water line and the hot and cold lines. I have 1 inch lines coming in from hot water heater and the main line, and I'm using sharkbite pex tubing.
Asked by txth4u2001 11 years ago
Add your answer
Verified Reply- SupplyHouse StaffFor a 1" supply use sku 46656 to thread onto the manabloc, and then sku U094LF to connect the pex tubing to the 1" male thread on the supply adapter.
here is the page with the supply adaptors.....it all depends on male or female fitting at your supply end. You do have to use the manabloc adaptor.....proprietary threads. http://www.supplyhouse.com/MANABLOC-Supply-Adapters-764000 hope this helps.
The manabloc supply inlets/outlets all require special Viega manabloc adapters. These have straight threads on the manabloc side of the adapter. They seal against the manabloc with a rubber washer similar to a hose bibb. Note that the threads on the supply inlets/outlets are NOT pipe threads and will not seal with pipe dope. I have read about these threads getting ruined by people trying to connect directly to the manabloc with a female pipe fitting. As long as you use a manabloc supply adapter, you can pick any that work with your chosen supply lines and pex connection method... The adapters are available to directly connect to 3/4" or 1" supply pipe. (You would likely pick an adapter for 1" pipe.) The connection options are PEX crimp, PEX press, compression ring, and pipe thread. Your choice will depend on the connection method that you have chosen for your plumbing system. If you are using PEX crimp or press throughout your system, you can use one of those adapter choices to connect directly to the manabloc. If you are using the sharkbite fittings that don't require PEX tools, you can use the male NPT adapter. Connect this to your PEX supply pipe with an additional Sharkbite/female NPT adapter. The compression adapter seems to only be available to fit 3/4" supply lines. My system has sharkbite tubing with PEX crimp fittings throughout my system, but somehow I ended up with NPT manabloc adapters. All of these required that I use an additional adapter on each supply line...female NPT / PEX crimp or female NPT / Sharkbite.
Q: what size is oring?
Asked by bg 11 years ago
Add your answer
Verified Reply- Supplyhouse StaffViega, does not provides us with those specs
Q: What is the inside diameter of this Supply Adapter on the NPT end?
Asked by Dr. Watson 12 years ago
Add your answer
It would be nominal pipe size. (The diameter of schedule 40 1" pipe) Slightly smaller than 1". Garland Sonsel
The inside diameter is of no use on NPT connections. If your idea was to sweat a pipe inside this adapter it will not work. It is designed for a 1" NPT coupler to join a supply line. 1" NPT to copper or PEX is available as an adapter. Sent from my iPhone
Q: I will be using 1" pex supply going to your 24 port manabloc 3/4" inlet. What adapter do I use to make the connection. I am continuing the 1" run from the manabloc to the water heater. Is the same adaptor used to continue the 1" to the water heater and what adaptor is used to connect to the water heater? Thank you so much for all your help,your sit is the absolute best at getting answers and is an asset when deciding who to purchase material from. Again thank you,John
Asked by John 12 years ago
Add your answer
Verified Reply- SupplyHouse StaffThis 46656 adapter can be used to connect 1" PEX at MANABLOC supply inlets. An additional 1" PEX x FNPT fitting would also be needed. You can use one of the "supply" ports on the cold side (top or bottom) to feed your water heater as illustrated in the diagram at the link below using the same adapters. http://blog.supplyhouse.com/wp-content/uploads/2013/08/diagram.jpg
Q: Is Teflon tape required between the supply outlet adapter and the pex fitting.
Asked by nA 12 years ago
Add your answer
Verified Reply- SupplyHouse StaffYou should not use teflon tape or any type of thread sealant at the connection between the threaded supply adapter and Manabloc body, but you should use teflon tape at the NPT end of the supply adapter (i.e. where it would connect to a female NPT fitting).
No
If the supply outlet adapter or the pex fitting has a rubber seal that seals the joint between the two fittings when tightening the threads, then teflon tape is not needed. Beware that Teflon tape may damage plastic threads especially when threading with metal threads on to it. So it may be better in this situation to use plumbers putty. Hope this helps. Doug.
Q: Is the Male NPT of this adapter compatible with the Female NPT of the Sharkbite 3/4 adapter model # U088LF? I need to make sure that the threads match. Thank you.
Asked by Brian 13 years ago
Add your answer
Verified Reply- PexSupply StaffYes, NPT is national pipe thread, so it is a standard thread that will work with other NPT fittings (including the Sharkbite female-threaded adapter you inquired about)
Yes, it will work, npt is the size and space of the threads
Hi, These parts comply with ANSI-NSF and ASTM standards. Since both items are standard ¾” size, they should fit fine. A 3/4” diameter item will have 12 Threads per inch and the mating dimension is exact( ¾”).
Yes, the male threads on the Manabloc adapter are standard 3/4" tapered pipe threads.
Q: When installing this adapter onto the Manabloc, besides the o-ring that comes with the adapter, is a washer required between the manabloc and this adapter? If so, does the washer come with the adapter?
Asked by Der Hosemeister 13 years ago
Add your answer
Verified Reply- PexSupply StaffNo washers are needed in addition to the one included with the supply adapter.
No addl washer needed
Be sure to install all adapters on this fitting first before installing it on the manabloc this supply adapter comes with it sealing element ( oring) no other washer or thread sealant should be used & do not over tighten or damage may result book says hand tighten only y'all. Have a good day Sent from my iPad
No other washers are required other than the supplied o-ring that comes with the adaptor.
I installed three of these by simply screwing it on the Manabloc. Only had an o-ring, no washer was used. My installation appears fine - no leaks after about one month. Hope this helps.
Q: Which supply adapter is best to connect from a 1" copper supply line to a manabloc?
Asked by Perplexed 14 years ago
Add your answer
Verified Reply- PexSupply StaffIt would be easiest to use a part 46656 MANABLOC supply adapter, along with a WP3-16 (sweat connection) or U094 (SharkBite connection) fitting.
Q: Will this fit the Miniblock as well as the Manablock
Asked by Todd 14 years ago
Add your answer
Verified Reply- PexSupply StaffYes, MANABLOC and MINIBLOC units use the same supply adapters.
Yes these fit the Miniblock's and full size blocks as well.
Q: What is the recommended adapter to connect 1/2 water pipe to a 1/2 Manablock system?
Asked by 14 years ago
Add your answer
Verified Reply- PexSupply StaffSupply adapters are only available in 3/4" and 1" sizes (1/2" would not provide an adequate amount of water to the manifold). The distribution ports, on the other hand, work with either 3/8" or 1/2" PEX. Those fittings come with MANABLOCs, in the amount, size, and style ordered.
