1/2" ProPEX ProPEX Washing Machine Outlet Box w/ Valves (Lead Free)
 --%3E %3Csvg version='1.1' id='Fill' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23F15C02' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
 --%3E %3Csvg version='1.1' id='Half' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cg%3E %3Cpath fill='%23F15C02' d='M30.05,70.23l3.79-12.01L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1h1.58 L93.71,7.18c-3.58-3.82-8.66-6.23-14.28-6.23H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,5.41,2.22,10.32,5.79,13.88 L30.05,70.23z'/%3E %3C/g%3E %3Cpath fill='%23FBC8B4' d='M93.71,7.18L60.98,39.6H91.2L65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82l5.55-17.59L6.75,93.32 c3.55,3.54,8.44,5.73,13.82,5.73h58.87c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,15.4,97.01,10.69,93.71,7.18z'/%3E %3C/svg%3E){kind=small}
MANUALS (2)
Product Highlights
Description
Uponor's lead-free brass transition fittings, valves and wall boxes carry the NSF us-pw-G marking for lead-free compliance to meet state lead-free legislation, and exceed the U.S. Safe Drinking Water Act. Now you can combine lead-free brass fittings with Uponor's PEX tubing, EP offering and ProPEX Out-of-the-Wall Support System for a complete lead-free solution from the inlet to the faucet. The new lead-free offerings feature Uponor's unique ProPEX fitting system for strong, durable connections without the need for torches, glues, solvents or gauges.
Specs
| Inlet Type: | PEX Expansion |
|---|---|
| Product Type: | Washing Machine Outlet Box |
| Size: | 1/2" |
| PEX Size: | 1/2" |
| Standards Met: | ASTM F1960 ASME A112.18.1 CSA B125.1 |
| Material: | Brass |
| Fitting System Compatibility: | Expansion PEX |
| Tubing Compatibility: | PEX |
| Lead Free: | Yes |
| Max Pressure (PSI): | 200 |
| Max Temp (F): | 200°F |
| Warranty: | 2 Year |
Questions?
Compare Similar Products
ASME A112.18.1
CSA B125.1
You May Also Need
Product Reviews
Most Liked Positive Review
Good Product - Propex connections make i
Most Liked Negative Review
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Buy any other laundry box
Valves are very stiff, hard to operate
Buy any other laundry box
Worked Perfectly
Quality Washer Box
Very high quality
First time buyer
Worked great
Superior product
Easy install
Propex washing machine box
Product Q&A
6 QuestionsQ: does this come with air hammers preinstalled like some other brands and your dishwasher connector for pro pex do?
Asked by nancy the newbie 12 years ago
Add your answer
This does not come with air hammers. You really don't need them with Pex. I have installed several of these outlets and never heard even a peep of water hammer.
Does not come with water hammer arrestors , however since you are using pex there will not be the banging associated with water hammer. unless you have household pressure exceeding 60 psi you probably don't need to worry about it.
Q: Is the box made of ABS, PVC or ? What type of glue is compatible with the integral 2" adapter fittings?
Asked by lightweight 12 years ago
Add your answer
Verified Reply- AnonymousThe box is made of high-impact polystyrene.
No glue is required. The valves attach to the box via the supplied nuts. The valves have a barbed fitting, which accepts 1/2" pex tubing. You must have an expansion tool, 1/2" collars, and 1/2" pex tubing to make the connection
Q: This says 1/2" but does that mean 1/2" ProPex tubing to 1/2" washing machine hose? My experience is all washing machines use 3/4" standard garden hose threading hookups. What does this have for the threaded end?
Asked by Nicholas 12 years ago
Add your answer
Verified Reply- SupplyHouse StaffThe valves included with this box connect to 1/2" PEX-A grade tubing at the inlets via a ProPEX connection (proper expansion tool required). The outlets have standard 3/4" garden hose thread.
The 1/2 inch is for the ProPex connection. Washing machine is still the 3/4 inch
Hiya Without looking with a ruler I would say it uses the ¾" hoses for the washing machine. I installed my system without any problems. Good luck Sent from my iPad
It's a standard washing machine fitting for 1/2 inch propex. My hoses are the same on both ends that I attached between the washer and these fittings.
it's 1/2" pex to 3/4 hose
The threaded coupling for the washer hose is standard size (3/4"). You'll be fine. I installed one of these a couple years ago and hooked up a typical washer hose from Home Depot to it. Sent from my iPhone
yep it's 1/2 inch PEX to standard washer dryer. Becareful if you have an inspection though, this box failed in San Francisco because it has to be a metal box to pass code here. No idea what your local code is, here in CA they are ridiculous! All the Best, Trip
Q: What size drain pipe will this accept?
Asked by miked_babaganoush 14 years ago
Add your answer
I bought one of these a year or so ago, and it installed nicely. The PVC drain pipe that fits it is 2". I just measured it to be sure. Good luck with your project! - Doug
I think it's an 1 1/2" PVC.
This has two receptacles which accept 1-1/2" drain line. Connections are made with standard pvc pipe cement.
2 inch sch 40
Mine is on a 2" stand pipe behind the washer.
This and all laundry wall boxes I have seen use 2" drains.
2 inch
1-1/2" drain Wes Sims
Q: Is there any way to connect the valves to a Shark Bite fitting?
Asked by Pete 15 years ago
Add your answer
Verified Reply- PexSupply StaffNo--this is a ProPEX fitting.
Pete, I am a beginner with plumbing, but I can tell you that the ProPEX type fitting is unique. It should only be used with the expander tool, expander rings, and PEX-A tubing. Shark Bite fittings look similar to ProPEX but they are not the same. Most hardware stores sell Shark Bite valves, then all you would need is a traditional washing machine outlet box.
Pete, I'm no professional, but after using this product and the sharkbite brand I'd have to say no. The rings on the connection are completely different.
Q: Can you give me the dimensions on this product?
Asked by Sonya 16 years ago
Add your answer
Verified Reply- PexSupply StaffYou can take a look at this document for the dimensions: http://s3.pexsupply.com/manuals/1263930927330/24308_PROD_FILE.pdf
