$132.28 each
In Stock
Get 3 Wed, Jul 8
MANUALS (1)
This item replaces: 10999
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
115/230V
1550 RPM
CWOSE
1/10 HP
0.56 Amps
4-25 Watts
Description
–
The new EC Max® RM refrigeration motor is the newest member of the EC Max line - it is specifically designed with refrigeration contractors in mind. It covers a wide range of watts, thereby reducing your inventory. The back of the motor features 5 drilled & tapped holes for mounting on various OEM applications as well as double foot pad mounting options.
The front of the motor features four threaded holes designed to easily adapt to various top-mount applications.
Product Features
The front of the motor features four threaded holes designed to easily adapt to various top-mount applications.
Product Features
- 4-25 Watt Constant Speed ECM - High Efficiency and Wide Replacement Capability
- IP67 Protection Against Dust and Water (Submersible up to 30 Minutes)
- Input Voltage Sensing Technology (115/230V)
- Mounting Hardware Included
- Double Foot Pad Design with Threaded Mounting Holes Opposite Shaft End
- Ball Bearing Design for All Angle Mounting
Specs
–
| Amperage: | 0.56 |
|---|---|
| Voltage: | 115/230V |
| Hertz: | 60/50 |
| Horse Power: | 1/10 |
| Rotation: | CWOSE |
| Motor: | ECM |
| Speeds: | 1 |
| Enclosure Type: | Totally Enclosed Air Over (TEAO) |
| RPM: | 1550 |
| Wattage: | 4-25 |
| Phase: | 1 |
| Bearings: | Ball |
| Operating Temp Range: | -40°F to 130°F |
| Warranty: | 2 Year |
