FG12 has been discontinued
Discontinued May 31, 2022
This product was discontinued by the manufacturer.
MANUALS (4)
'/%3E%3C/svg%3E){kind=small}
Direct Replacement:
FG Series Round Inline Exhaust Fan, 12" Duct (940 CFM)
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Product Highlights
–
1.87
741 CFM
5 Year Warranty
12"
120v
2600 RPM
Description
–
Fantech's versatile FG Series Inline Fans are virtually airtight. Galvanized steel housings meet code requirements for both residential and commercial applications. High quality ebm-papst motors ensure long life and dependable performance.
The FG Series features new longer duct connections for easier installation. Fans are prewired and include the bracket for mounting to wall or ceiling. Straight-through airflow allows fans to be installed at any angle at any point along the duct work.
Features:
The FG Series features new longer duct connections for easier installation. Fans are prewired and include the bracket for mounting to wall or ceiling. Straight-through airflow allows fans to be installed at any angle at any point along the duct work.
Features:
- Airtight galvanized steel housing - perfect for commercial code applications
- Powered by ebm-papst external rotor motorized impeller for excellent heat dissipation, even at low RPM
- Backward curved impeller
- Permanently lubricated sealed ball bearings for maintenance free operation
- Automatic reset thermal overload protection
- 100% speed controllable
- Rated for air stream temperatures up to 140°F
- Rated for outdoor use
- 5-Year factory warranty
Specs
–
| Duct Size: | 12" |
|---|---|
| Voltage: | 120v |
| RPM: | 2600 |
| Air Flow Capacity (CFM): | 741 |
| Rated Watts: | 181 |
| Max. Amps: | 1.87 |
| Housing Material: | Galvanized Steel |
| Warranty: | 5 Year |
| 0" Ps: | 741 CFM |
| 0.2" Ps: | 680 CFM |
| 0.4" Ps: | 601 CFM |
| 0.6" Ps: | 515 CFM |
| 0.8" Ps: | 434 CFM |
| 1.0" Ps: | 363 CFM |
| 1.5" Ps: | 236 CFM |
| 2.0" Ps: | 141 CFM |
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
You May Also Need
1 Replacement Part
Screws Kit Electric Box for FG Series
SKU: 484049
Fantech
Need help finding a replacement part?
Fill out the part request form and someone will get back to you shortly.
PART REQUEST FORM
Product Reviews
4.33 out of 3 reviews
100% would recommend this product
5 star
67%
4 star
0%
3 star
33%
2 star
0%
1 star
0%
Showing 1-3 of 3 reviews
I would buy this product again
This is a great product used it as a return fan and it works great. Very easy to install...it was also a very good price compared to some of the other fans that are out there.
Bobby J
okc, oklahoma
8 years ago
Verified Buyer
Was this review helpful to you?
Good products
I use these fan for commercial use for my projects. Good products and excellent shipping.
FDOT CAD
Pinellas park, Florida
8 years ago
Verified Buyer
Was this review helpful to you?
sound level higher than expected
use for exhaust into garage for super-insulated house
RT
Colebrook, NH
16 years ago
Verified Buyer
Was this review helpful to you?
Product Q&A
1 Question1 Question
Q: Any relative idea on how loud this fan is? I am considering to have this installed outside an office wall and I am worried that it might be annoying. Any ideas? Too bad they don't list a dB spec.
Asked by eric 12 years ago
Add your answer
Verified Reply- Supplyhouse Staffthey are pretty quiet as long as mounted w isolator and canvas duct connectors to mitigate vibration.
